Terex Ecotec TDS 820 Shredder Illustrated Parts Catalog Revision 5.0

Description

Terex Ecotec TDS 820 Shredder Illustrated Parts Catalog – Revision 5.0

This Terex Ecotec TDS 820 Illustrated Parts Catalog is the parts identification document for the TDS 820 shredder, issued at Revision 5.0 and dated 24-04-2026. Every figure is built around exploded artwork with numbered callouts, and each callout is tied to a part number, description, quantity and, where it matters, a serial-number note telling you which build of the machine the part belongs to. If you own, service or rebuild a TDS 820, this is the document that turns a photograph of a broken component into an orderable part number.

File Details

• Manual type: Illustrated Parts Catalog
• Brand: Terex Ecotec
• Model: TDS 820 (also covers TDS 820E references)
• Revision: 5.0
• Date of issue: 24-04-2026
• Language: English
• Page count: 329 pages
• Format: PDF

Chapters Covered

• Understanding Your Machine Serial Number
• TDS 820 Machine Overview
• Safety Decals Overview, ANSI Decal Lists 1-4 and ISO Decal Lists 1-4
• Chassis: Chassis Overview, Chassis ASM 1 and ASM 3, Front RHS Guard, Front Right Door, Rear Right Door Engine Access, Rear Door Complete (early and later serial builds), Rear Left Door Hyd Tank Access, Front Left Door Urea Tank Access, Front LHS Guard
• Track / Wheeled: Track ASM, Track ASM Hoses and Fittings, Strickland Tracks
• Hopper / Feeder / Grid: Hopper ASM, Feeder ASM, Feeder Ram Hoses and Fittings, Hydraulic Hopper Lower and Upper ASM
• Powerunit: Tier 4 Powerunit ASM, Tier 3 and Tier 4 Powerunit Sub Frame ASM, Tier 4 Scania DC13 Engine ASM 1 and 2, Tier 3 / Tier 4 / Stage V Scania DC13 Engine ASM 3, Engine Pump Hoses and Fittings ASM 1-3, Engine Pressure Filter ASM, Tier 4 and Stage V Water Trap ASM, Tier 4 Engine Cooling Pack ASM 1, Tier 3 / Tier 4 / Stage V Engine Cooling Pack ASM 2, Tier 3 Powerunit ASM, Tier 3 Scania DC13 Engine ASM 1 and 2, Tier 3 Engine Cooling Pack ASM 1
• Stage V Scania DC13 Powerunit Overview, Sub Frame ASM, Engine and Exhaust Overview, Exhaust ASM, Engine ASM, Cooling Pack ASM and Control Unit Complete ASM
• Urea Tank ASM
• Hydraulic Tank ASM 1, 2 and 3
• Fuel Tank ASM and Port Diverter ASM
• Shredder: Shredder Overview, Shredder Motor (early and later serial builds), Shredder Housing Parts for 9/9-4 and 7/7-4 shafts, Shredder Shafts, Shredder Shaft Bearings, Shredder Outlet Chute ASM
• Conveyors: Main Conveyor overview, lower sections 1-4 and upper sections 1-2, Main Conv Motor Hoses and Fittings, Main Conv RAM Hoses and Fittings 1 and 2, Transfer Conveyor and Transfer Conveyor Head Section, Long Product Conveyor overview and upper/lower sections, Product Conveyor variants for specific serial numbers
• Electrics: TDS 820 Control Panel Spares, Control Panel Internals, Operator Control Panel, Radio Kit, Additional Electrical Spares
• Hydraulics: Chassis Oil Cooler ASM, Nimco Handles Rear Vertical ASM, Walvoil Handles Rear Vertical ASM, N/O Ventable Relief Valve, Sauer Danfoss PVG 32 Hoses and Fittings 1 and 2, High Pressure O-Rings, Hydraulic Ram Hoses and Fittings, Hydraulic Ram 2 Hoses and Fittings, Hopper Hydraulics Details
• Options: Standard Magnet ASM, Magnet Breakdown ASM, Magnapower Rare Earth Magnet ASM, Rare Earth Magnet Breakdown, Hydraulic Magnet ASM, Standard Magnet Breakdown, Hydraulic Magnet Control Valve and Solenoid ASM, Wagner Rare Earth Magnet ASM
• General Information, Spare Parts Enquiry, Parts Support Good Practice, Track Identification Plate, Engine Serial Plate, PDM and PLC Software Versions, Machine Navigation, Paint Codes

Across those sections the Terex Ecotec TDS 820 parts catalog gives you a complete assemblies-down-to-fasteners breakdown of the machine. Brackets, guards, hinges, latches, seals and cover plates are listed alongside the major assemblies, and the fastener lines carry full thread, length, grade and standard references so you can match a bolt exactly rather than approximately. Hydraulic hoses are given their own part numbers throughout, and filter elements, seal kits, sensor part numbers and bearing groups are all called out as separate line items. The decal sections are itemised to the individual decal part number, which is the practical way to restore a machine to a legible, compliant condition.

Serial Number Sensitivity

This catalog is unusually serial-aware, and that is one of its real strengths. Many figures are split into two or more versions depending on the machine build, with the break points spelled out in the notes column – for example the rear door complete assembly, the shredder motor, the engine pressure filter assembly, the main conveyor pivot pins, the tail and drive drums, the magnet assemblies and the rear vertical control handles. Before ordering, the catalog directs you to the track identification plate on the outside face of each track and to the engine serial plate, and it explains that control panels, PC boards and Hetronic remotes are serial-number dependent items with their own numbers on the component. Following those steps is what prevents a wrong part arriving on site.

Why This Terex Ecotec TDS 820 Parts Catalog Matters

Ordering shredder parts without a catalog usually means guesswork, and guesswork on a machine of this size is expensive in both money and downtime. This document removes that risk. You can identify the exact part number for a worn conveyor scraper, a failed bearing housing, a shredded bellows, a leaking hydraulic ram, a cracked guard, a replacement filter element or a complete magnet assembly, then confirm it against your machine serial number before you commit. It supports planned maintenance just as well as breakdown repair, letting you build a spares list in advance for the items that fail most often on a TDS 820. Paint codes are included so touch-ups and repainted panels match correctly, and the decal lists let you keep the machine’s safety markings correct.

IMAGES PREVIEW

Delivery is instant. The PDF is available to download immediately after checkout, with no shipping and no waiting on a physical book. Read it on a phone in the yard, on a tablet next to the machine, or on a workshop PC, and print only the figures you actually need for the job in front of you.
