Tigercat S855D LS855D SHOVEL LOGGER SERVICE MANUAL – PDF DOWNLOAD

DESCRIPTION:

Tigercat S855D LS855D SHOVEL LOGGER SERVICE MANUAL – PDF DOWNLOAD

SERIAL NUMBER 85552001 TO 85553000
SERIAL NUMBER 85502001 TO 85503000

INTRODUCTION :

An Operator’s manual, Service manual and a Parts catalog are made available by Tigercat to assist the dealer, customer and operator in becoming familiar with the features of the S855D/LS855D Shovel Loggers.
Serial numbers:
S855D 85552001 TO 85553000
LS855D 85502001 TO 85503000

• The S855D/LS855D Shovel Loggers are designed for log transferring, loading, and shovel logging
  (hoe-chucking) by swinging logs closer to the roadside minimizing ground surface impact and damage.
• The operator’s manual will assist the operator with the techniques of proper and safe operation of the S855D/LS855D Shovel Loggers. There is also important information regarding the safe operation of the attachment. The service manual contains safety and servicing procedures and a preventive maintenance schedule to ensure optimum machine performance.
• Section 1 in both the operator’s manual and the service manual contains safety information that must be followed. As well, throughout the rest of the manuals, DANGER, WARNING and CAUTION notices are displayed where necessary, drawing attention to possible hazards when performing certain procedures.
• Only trained personnel should be allowed to operate or work on the machine.
• The information contained in this manual is current at time of printing. Improvements to the machine are on-going and may not be covered, therefore in these cases contact your Tigercat dealer for the appropriate information.
• The phrase “and up” appearing in this manual after the serial number implies the related information is current for any machine serial number HIGHER than the serial number preceding the “and up”.
• Tigercat reserves the right to make changes to the machine after this manual release date that may not immediately appear in this manual.

TABLE OF CONTENTS:

Tigercat S855D LS855D SHOVEL LOGGER SERVICE MANUAL – PDF DOWNLOAD

INTRODUCTION……………………………………………………………………………………………………………………………….v
MACHINE IDENTIFICATION AND SERIAL NUMBERS………………………………………………………………………….vi
STANDARDS, FOPS, OPS, ROPS, TOPS …………………………………………………………………………………………..vii
NON-APPROVED FIELD PRODUCT CHANGES ………………………………………………………………………………..viii
REGULATORY INFORMATION…………………………………………………………………………………………………………..ix
SAFETY……………………………………………………………………………………………………………………………………………1
CONTROLS AND OPERATION……………………………………………………………………………………………………………2
LUBRICATION AND MAINTENANCE…………………………………………………………………………………………………..3
HYDRAULIC SYSTEM……………………………………………………………………………………………………………………….4
PILOT SYSTEM…………………………………………………………………………………………………………………………………5
ELECTRICAL AND COMPUTERS………………………………………………………………………………………………………..6
ENGINE AND ANTI-STALL………………………………………………………………………………………………………………….7
COOLING SYSTEM………………………………………………………………………………………………………………………….10
TRACK DRIVE…………………………………………………………………………………………………………………………………11
BOOM FUNCTIONS…………………………………………………………………………………………………………………………12
LEVELING………………………………………………………………………………………………………………………………………13
SWING……………………………………………………………………………………………………………………………………………15
GRAPPLE AND POWER CLAM GRAPPLE…………………………………………………………………………………………17
LIVE HEEL………………………………………………………………………………………………………………………………………18
FELLER DIRECTOR (BAR SAW)……………………………………………………………………………………………………….19
MISCELLANEOUS…………………………………………………………………………………………………………………………..25
