Topcon Super D Camera Service Manual- PDF DOWNLOAD

Description

Topcon Super D Camera Service Manual

FILE DETAILS:

LANGUAGE:ENGLISH
PAGES:68
DOWNLOADABLE:YES
FILE TYPE:PDF
TOPCON SUPER D CAMERA SERVICE MANUAL- PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

Topcon Super D Camera Service Manual

Detaching the Front Cover Plate ‘ 1. Detach the lens locking lever. (Fig.1) Unscrew its fixing screw (32A 4007). CAUTION Be careful; as the spring (32A 4008) may be lost. . 2. Detach the tripod socket plate.(Fig.2) Unscrew its three fixing screws. 3. Detach the front cover plate. (Fig.3) …Unscrew two fixing screws on top. Also, unscrew two fixing screws on the bottom. (Fig.4) Detaching the’Bottom Cover Plate 1. Unscrew two?fixing screws at both . ends. ‘ (Fig.5) 2. Unscrew the battery compartment cover and the motor drive shaft cover (with the screw cap driver AAOlOl) CAUTION The battery, rewind button, cover plate and spacer will become free, at this time, and should be placed aside. ea Cece:
