UH-60A UH-60L EH-60A Black Hawk Helicopter Operator's Manual TM 1-1520-237-10
UH-60A UH-60L EH-60A Black Hawk Helicopter Operator's Manual TM 1-1520-237-10 - Image 2
UH-60A UH-60L EH-60A Black Hawk Helicopter Operator's Manual TM 1-1520-237-10 - Image 3

UH-60A UH-60L EH-60A Black Hawk Helicopter Operator’s Manual TM 1-1520-237-10

Original price was: $39.95.Current price is: $24.95.

Complete operator’s manual for UH-60A, UH-60L and EH-60A Black Hawk helicopters – 836 pages covering systems, flight procedures, emergency procedures, performance data, avionics, armament and mission equipment.

SKU: UH60A-L-EH60A-OPM-TM-1-1520-237-10-HD Category: Tags: , , , Vendor: Compressor Docs
⚡
Instant PDF Download
Available immediately
💾
Save to Your Device
Download & keep forever
🛡️
Antivirus Scanned
100% virus-free
🌍
Trusted Worldwide
175,000+ customers

Description

UH-60A, UH-60L and EH-60A Black Hawk Operator’s Manual – TM 1-1520-237-10

This is the full Operator’s Manual for UH-60A, UH-60L and EH-60A Helicopters, published by Headquarters, Department of the Army as Technical Manual TM 1-1520-237-10, originally dated 31 October 1996 and updated through Change 10 dated 30 September 2002. At 836 pages, it is the complete operating reference for the entire Black Hawk family covered by this manual, from the earliest UH-60A through the UH-60L and the specialized EH-60A electronic warfare variant.

Every system, limit, procedure and performance chart a crewmember needs to operate this helicopter safely is contained in this one document. It is written for the operator rather than the depot-level maintainer, which makes it unusually direct and usable – instructions are stated as steps to be performed, with warnings, cautions and notes placed exactly where they matter.

File Details

  • Manual type: Operator’s Manual (Technical Manual)
  • Document number: TM 1-1520-237-10
  • Original date: 31 October 1996
  • Latest change: Change 10, 30 September 2002
  • Brand / manufacturer: Sikorsky / United States Army
  • Models covered: UH-60A, UH-60L, EH-60A
  • Engines covered: T700-GE-700, T700-GE-701C
  • Language: English
  • Page count: 836 pages
  • File format: PDF

Chapters Covered

  • Chapter 1 – Introduction: General description, warnings/cautions/notes, appendix references, abbreviations, change symbols, series and effectivity codes.
  • Chapter 2 – Aircraft and Systems Description and Operation:
    • Section I – Aircraft (dimensions, turning radius, compartment diagrams, consoles, landing gear, instrument panel, doors, crew seats, troop provisions)
    • Section II – Emergency Equipment (fire protection, crash axe, first aid kits)
    • Section III – Engines and Related Systems (T700 engine, fuel supply, alternator, ignition, anti-icing, oil system, start system, controls, HIRSS, instruments)
    • Section IV – Fuel System (tanks, selector control, filter, prime, quantity indicating, boost pumps, refueling)
    • Section V – Flight Controls (cyclic, collective, mixing unit, servos, AFCS, SAS, trim, FPS, stabilator)
    • Section VI – Hydraulic and Pneumatic System (pump modules, backup system, leak detection/isolation, transfer modules, servicing)
    • Section VII – Powertrain System (main transmission, input/accessory/main modules, lubrication)
    • Section VIII – Main and Tail Rotor Groups (blades, hub, gust lock, tail rotor quadrant)
    • Section IX – Utility Systems (windshield wipers, pitot heater, rotor blade deice kit, blackout curtains, wire strike protection, flight data recorder)
    • Section X – Heating, Ventilating, Cooling and Environmental Control Unit
    • Section XI – Electrical Power Supply and Distribution Systems (dc, ac, auxiliary, external, APU)
    • Section XII – Auxiliary Power Unit
    • Section XIII – Lighting (interior, exterior, NVG)
    • Section XIV – Flight Instruments (pitot-static, attitude, turn rate, airspeed, altimeter, compass, master warning)
    • Section XV – Servicing, Parking and Mooring
  • Chapter 3 – Avionics:
    • Section I – General (equipment configuration, power supply, antennas, intercom C-6533/ARC)
    • Section II – Communications (AN/ARC-186, AN/ARC-201, AN/ARC-164, AN/ARC-220, KY-58, KY-100)
    • Section III – Navigation (LF/ADF AN/ARN-89 and AN/ARN-149, VOR/ILS/MB AN/ARN-123 and AN/ARN-147, Doppler AN/ASN-128, Doppler/GPS AN/ASN-128B, IINS AN/ASN-132, gyro magnetic compass, VSI/HSI display system)
    • Section IV – Transponder and Radar (AN/APX-100 IFF, KIT-1A/TSEC, KIT-1C, radar altimeter AN/APN-209)

    Complete PDF Bookmark Tree

    Complete Bookmarks

    The complete bookmarks in the “UH-60A UH-60L EH-60A Black Hawk Helicopter Operator's Manual TM 1-1520-237-10” are as follows:

    TABLE OF CONTENTSp. 27
