US Army M809 Series 5-Ton 6×6 Truck Maintenance Manual TM 9-2320-260-34-1 Volume 1 – PDF Download

Description

US Army M809 Series 5-Ton 6×6 Truck Maintenance Manual – TM 9-2320-260-34-1 Volume 1

This is Volume 1 of 2 of the official TM 9-2320-260-34-1 technical manual covering Direct Support and General Support maintenance for the 5-ton, 6×6, M809 series diesel trucks. It is the depot-level and support-level companion to the operator and unit maintenance manuals, and it goes into the engine, driveline and brake systems in genuine component-by-component detail.

Every task in this M809 series truck maintenance manual follows the same military workflow: an INITIAL SETUP block listing applicable models, special tools, test equipment, materials, personnel, references, equipment condition and general safety instructions, followed by step-by-step removal, cleaning and inspection, repair, assembly and installation procedures. Warnings, cautions and notes are called out inline where they matter. Each task ends with FOLLOW-ON TASK(S) so you know exactly what has to happen next.

File Details

• Manual type: Direct Support and General Support Maintenance Technical Manual (Volume 1 of 2)
• Document number: TM 9-2320-260-34-1
• Supersedes: TM 9-2320-260-34-1, TM 9-2320-260-34-2-1, TM 9-2320-260-34-4-2 and TM 9-2320-260-34-2-5, 31 December 1980
• Brand / Manufacturer: U.S. Army (Cummins NHC-250 powered vehicles)
• Models covered: M813, M813A1, M814, M815, M816, M817, M818, M819, M820, M820A1, M820A2, M821
• Language: English
• File format: PDF
• Distribution statement: A – Approved for public release, distribution unlimited

Chapters Covered in Volume 1

• How To Use This Manual
• Chapter 1 – Introduction (General Information, Equipment Description and Data)
• Chapter 2 – Service and Troubleshooting Instructions
  • Repair Parts, Special Tools, TMDE and Support Equipment
  • Mechanical Systems Troubleshooting (100 indexed malfunctions across engine, fuel, clutch, transmission, transfer, differential, steering, air compressor, PTO, dump body, crane, liftgate, winterization kits and winches)
  • General Maintenance Instructions (cleaning, inspection, repair, assembly precautions, painting)
• Chapter 3 – Engine Maintenance
  • Description and Data
  • Engine (In-Vehicle) Maintenance – water header plates, vibration damper, crankshaft flange, fan hub, accessory drive, intake and exhaust manifolds, oil cooler, rocker lever housings, crossheads, cylinder heads, cam follower housings, oil pan, flywheel
  • Engine Replacement
  • Engine Disassembly into Subassemblies
  • Engine Repair – cylinder liners and block, cylinder head repair, oil pump repair
  • Engine Assembly from Subassemblies
  • Engine Valve and Injector Maintenance – valve refacing, seat inserts, injector sleeves, seat grinding, injector timing, injector and valve adjustment (dial indicator and torque methods), top stop plunger travel

  IMAGES PREVIEW







• Chapter 4 – Clutch Maintenance (clutch, release bearing, shaft and yoke, rotochamber for M816)
• Chapter 5 – Fuel System Maintenance
  • Description and Data
  • Fuel Injector Maintenance – non-top stop and top stop injectors, leakage test, pattern test, flow test
  • Fuel Pump Maintenance – replacement, spring pack, upper spring pack, damper, air cylinder, governor, housing, front cover, full calibration procedure
• Chapter 6 – Cooling System Maintenance (radiator, water manifold, water pump)
• Chapter 7 – Electrical System Maintenance (description and data, front and rear wiring harness replacement)
• Chapter 8 – Transmission Maintenance (twin poppet valve, gearshift lever, in-vehicle and out-of-vehicle replacement, full transmission and shifter housing overhaul)
• Chapter 9 – Transfer System Maintenance (front axle engagement air cylinder, transfer replacement, transfer repair)
• Chapter 10 – Axles and Suspension Maintenance (front axle, steering knuckle, wheel hub spindle, forward-rear and rear-rear axle, differential and carrier repair, oil seals)
• Chapter 11 – Compressed Air and Brake Systems Maintenance (air compressor, unloader valve, parking and service brakeshoe and brakedrum repair, air-hydraulic system)

What This M809 Series Truck Maintenance Manual Gives You

The troubleshooting chapter alone makes this volume worth having. One hundred numbered malfunctions are indexed with the page number of the procedure that fixes them – from “engine will not crank” and “engine cranks but will not start,” through transmission grinds and pops out of gear, transfer case noisy, differential clunks during turns, and all the way into dump body raise/lower faults, M816 wrecker crane swing faults, M819 tractor wrecker faults, hydraulic liftgate faults on the M820A2, winterization kit heater faults, and winch faults. Each malfunction is written as Step 1, Step 2, Step 3 with a decision at each step and a paragraph reference pointing into the repair chapter.

Because this is the Direct Support and General Support level, the procedures here go far deeper than the unit maintenance manual. Engine disassembly into subassemblies, cylinder liner and block maintenance, cylinder head repair, crankshaft and main bearing removal, piston and connecting rod work, camshaft maintenance, and complete fuel pump calibration on the test stand are all covered. Torque values, wear limits, tolerances and clearances are given in both inch and metric units throughout.

Covered Models and Engines

This M809 series maintenance manual covers the following configurations:

• M813 / M813A1 – Cargo Truck, W/W and WO/W
• M814 – Cargo Truck, W/W and WO/W
• M815 – Bolster Logging Truck, W/W
• M816 – Medium Wrecker Truck, W/W
• M817 – Dump Truck, W/W and WO/W
• M818 – Tractor Truck, W/W and WO/W
• M819 – Tractor Wrecker Truck, W/W
• M820 / M820A1 / M820A2 – Expansible Van Truck, WO/W
• M821 – Bridge Transporting Stake Truck, W/W

All M809 series vehicles in this manual are powered by the Cummins NHC-250 – a naturally aspirated, liquid cooled, overhead valve, four-cycle, in-line six-cylinder diesel. It runs a 15.8 to 1 compression ratio and develops 240 horsepower at 2100 rpm, with peak torque of 560 lb-ft at 1600 rpm. Both early model engines (before serial number 1124663) and late model engines (after serial number 1124663) are covered, including the clean air configuration and the change to top stop fuel injectors.

Why This Manual Matters for the M809 Series

The M809 series is a big, heavy, mechanically governed diesel truck. Get the injector and valve adjustment wrong and it runs rough, smokes, loses power, or dilutes the engine oil with fuel. Get the cam follower housing gasket thickness wrong and injector timing is off. Get the flywheel housing alinement wrong and you are pulling the transmission again. This manual is where those numbers and sequences live.

It also carries the support-level procedures that simply are not in the operator or unit manual: fuel pump calibration on the test stand with governor cut-off RPM, throttle leakage, idle speed, pump main pressure, governor fuel pressure and governor weight pressure all specified; fuel injector leakage, pattern and flow testing with the correct orifice plug and burnishing procedure; crankshaft and main bearing clearance measurement with plastigage; bevel ring gear and pinion tooth contact pattern checking with blue pigment and the exact shim moves for each contact pattern type; and differential backlash set to 0.005-0.015 in.

Safety and Special Tools Content

There is a full Warning Summary at the front of the manual covering exhaust poisoning symptoms, hearing protection above 85 dB, fuel flammability, eye protection for fuel system checks, hot coolant under pressure, overhead lifting device capacity for dump body work, asbestos brake lining dust handling, hydraulic line bleeding, and safe use of lifting devices on the engine and transmission. Each individual task also carries its own warning and caution callouts.

Get the TM 9-2320-260-34-1 Volume 1 PDF

The M809 series truck maintenance manual you are looking at enables real support-level work: engine in-vehicle repair and full engine replacement, complete engine teardown and rebuild, cylinder head and liner work, valve and injector service and calibration, clutch and transmission overhaul, transfer case repair, axle and steering knuckle service, differential rebuild, air compressor overhaul, and brake system service on the M813, M813A1, M814, M815, M816, M817, M818, M819, M820, M820A1, M820A2 and M821.

Correct procedures and the right torque values, wear limits and clearances are the difference between a truck that comes back into service and one that comes back into the shop. This manual gives you the specified values and the step order the Army uses.

Delivery is instant. After payment the PDF is available for download immediately – no shipping, no waiting on a paper copy. Open it on any device, follow it at the bench or in the cab, and print whichever pages you want to take to the truck. Volume 1 of 2 covers the engine, clutch, fuel, cooling, electrical, transmission, transfer, axles, suspension and air/brake systems; Volume 2 of 2 carries the steering, frame, body and special purpose bodies, winch and power takeoff, and special purpose kits.
