GENERAL INFORMATION
- This Parts catalog has been prepared for your convenience when ordering parts for ELECTRA GLIDE models FL. FLH, FLHS and SUPER GLIDE Models FX, FXE, FXS.
- Wherever possible parts are shown in assembly breakdown sequence. Index numbers shown in the illustrations correspond to index numbers in parts I ists. Consult the illustrations when ordering parts so you are sure to get just what you want.
- In most cases. only the latest parts are shown in the illustrations, however. parts lists cover some parts used as early as 1941. Number in parenthesis following description of part is the quantity needed for complete assembly shown in illustration. If there is no number in parenthesis, only one is used. Prices of all parts and accessories listed in this catalog are published separately in the latest RETAIL PRICE LIST. The following instructions should be followed very carefully when ordering parts:
- Specify the correct part number on each item. Check the ” Used On” column of the parts list which shows the model on which the part f its. Whenever in doubt, refer to the Vehicle Identification Number stamped on the engine crankcase. Two types of serial numbers are used:
- 1. 1969 and earlier: Serial number is located on the engine left crankcase. The first four or five digits represent the year and model – the same as shown in the “Used On” column in this catalog.
- 1970 and later: Vehicle Identification Number (V. I. N.) is located on the engine right crankcase and is the same as the number located on the frame steering head. The V. I. N. (vehicle identification number) for ELECTRA GLIDE and SUPER GLIDE models are as follows:
- • An asterisk ( *) in the “Used On” column indicates part is used upto and including 1978 models (the latest model year covered by this catalog).
- • Part-Numbers are to be used when ordering by TELEGRAM or CABLE
- • When ordering parts use our standard parts order blank Part No. 99511-76, for all parts except engines and crankcases. Order blank Part No. 99514-76 must be used for engines and crankcases. The use of these blanks will enable us to fill and ship your order more promptly.
- These blanks are furnished free of charge upon request. • Do not order motorcycles or advertising matter on Parts Order Blanks. Write nothing on the order blank except the order itself, as any other correspondence will not be answered until the order is shipped and billed.
- • Freight, Express and Parcel Post orders should be on separate order blanks. • For your own records, number and date all orders, also keep a carbon copy for reference in case of misunderstanding
TABLE OF CONTENTS:
1941-1978 Harley Davidson FL FLH FX FXE FXS PARTS CATALOG – PDF DOWNLOAD
Air Cleaner 23
Alternator – 1970 & Later 25
Axle – Front 75, 77, 79, 80, 83
Axle – Rear 75, 77, 81, 85
Headlamp 179, 180
Horn 193
Ignition Circ it Breaker 29
Indicator Lamps 181
Axle – Sidecar 215
Battery 167, 169
Brake – Front 57, 58, 61, 63, 65, 67
Brake – Rear 69, 70, 73
Brake – Sidecar 219
Brake Caliper – Front – FX, FXS 63
Brake Control – Front 57, 61
Brake Control – Rear – FX, FXS 70
Brake Control – Rear – FL, FLH 69
Brake, Disc – Master Cylinder 57, 58, 65
Bumpers 226
Carburetor – 1967 to 1970 20
Carburetor – 1971 to 1975 19
Carburetor – 1976 & Later 17
Cast Wheel – FL, FLH 75
Cast Wheel – Front – FX, FXS 83
Cast Wheel – Rear – FX, FXS 85
Center Stand 103
Chain 54
Chain Guard 141, 147
Chain Housing 144
Chain Oiler 144, 153
Choke 23
Circuit Breaker 29, 206
Clutch 48
Clutch Foot Control 51
Clutch Hand Control & Booster 53
Connecting Rods 7
Crankcase 11
Cycle Signal Lamp 175, 176
Cylinders 3, 6
Electrical 197
Exhaust Pipes 157, 159, 160, 161, 163, 165
Fairing 131 133, 137
Fender Lamp – Front 189
Instrument Panel 203
Jiffy Stand 103
Kick Starter 38
Leg Shields 135
Liberty Edition 229
License Plate Bracke t 143
Luggage Carrier & Box 121
Mirror – FXS 155
Mufflers 157, 159, 160, 161, 163, 165
Name plates 113, 121, 138, 150, 215
DiI Cooler 155
Oil Filter 154
DiI Pressure Switch 15
Oil Pump 15
Oil Tank 153
Passing Lamps , 190
Pistons 7
Points 29
Pursuit Lamps 190
Push Rods 3, 6
Radio Carrier 213
Rims 75, 77, 79 80, 81
Rocker Arms 3, 6
Saddlebags 215
Safety Guard 101
Seat 105, 107, 109, 110, 111, 113
Shifter 39, 43
Shock Absorbers 123
Sidecar Body 215
Siren 225
Spark Cables, Coil & Plugs 31
Speedometer 171,173
Spokes 75, 77, 79, 80, 81, 217
Spotlamps 190
Sprockets 54
Fenders 138, 141, 219
Fire Extinguisher 223
Starter Motor 33, 35, 37
Switches 199, 201, 206, 207 209
FLHS Parts 228
Flywheels 7
Footboards 115
Footrests 117, 119
Footshift 39
Fork – Front 86, 88, 91, 93, 95, 97
Fork – Rear 99
Frame 99
Frame – Sidecar 215
Gages • 205
Gas Tanks 149
Gas Tank Trim 150
Gaskets 3, 6
Gear Case Cover 11
Generator – 1958 to 1969 27
Handlebar 124
Tachometer 171, 173
Tail Lamp 113, 183
Tappets 3
Terminal Plate 203
Throttle Control 126
Timer 29
Tour-Pak 121
Transmission 44
Tune Up Kits 31
Turn Signals 185, 186
Valves 3, 6
Valve Covers 3
Voltage Regulator 211
Wheels 75, 77, 79, 80, 81, 83, 85, 217
Wl ndsh ield 129, 131, 133, 134
Warning 195
