2015 Ducati Scrambler 800 Workshop Manual – PDF Download

Description

2015 Ducati Scrambler 800 Workshop Manual – PDF Download

The 2015 Ducati Scrambler 800 Workshop Manual – PDF Download is a detailed 873-page workshop reference for the Ducati Scrambler 800. Its coverage extends from routine maintenance and model identification through electrical diagnosis, chassis service, fuel and exhaust work, and extensive engine disassembly, inspection and reassembly procedures. The manual also contains procedures and illustrations for the ICON, CLASSIC, URBAN ENDURO and FULL THROTTLE customisations where their components or dimensions differ.

File Details

• Manual type: Workshop Manual
• Brand / model: Ducati Scrambler 800
• Year shown: 2015
• Language: English
• Page count: 873 pages
• File format: PDF

Workshop Coverage Built Around the Scrambler 800

This manual is arranged as a technician’s working reference rather than a brief owner’s guide. It begins with safety information, repair practices, identification data and technical specifications, then moves into scheduled service, bodywork, electrical and engine-management systems, chassis assemblies, fuel and exhaust components, and the complete engine. Removal and refitting sequences are supported by photographs, coloured component illustrations, wiring-routing views, exploded-style graphics, tightening values and service measurements.

Model-specific information includes frame and engine identification patterns, while the technical-data section collects information needed before service work begins. The manual records the 803 cu. cm, longitudinal 90-degree L-twin four-stroke engine configuration, its 88 mm bore and 66 mm stroke, the desmodromic two-valve-per-cylinder timing system, six-speed transmission, wet mechanically controlled clutch, fuel-system data, brake specifications, suspension information, wheel and tyre data, fluid quantities and tightening torque settings.

Chapters Covered

• S.01 – General
  • Symbols, abbreviations and references
  • Product specifications and workshop products
  • Dangerous products, warnings and general safety rules
  • General maintenance and repair instructions
• S.02 – Model-specific information
  • Model identification
  • Frame and engine identification data
• S.03 – Technical data
  • Technical specifications, overall dimensions and colours
  • Lights, instrument panel and fuse data
  • Injection, fuel and ignition systems
  • Charging system, generator and battery data
  • Hydraulic brakes
  • Front and rear suspension, wheels and tyres
  • Gearbox, cylinder/piston and crankshaft data
  • Timing system, valves and transmission
  • Fuel, lubricants and other fluids
  • Engine and frame tightening torque settings
  • Diagnosis, frame and engine special tools
• S.04 – Maintenance operations
  • Vehicle pre-delivery checks
  • Customer and dealer scheduled maintenance charts
  • Rear shock absorber and control adjustments
  • Throttle and clutch cable adjustment
  • Front and rear brake pad inspection and replacement
  • Chain tension and steering-head bearing adjustment
  • Front and rear brake-fluid replacement
  • Air-filter service and spark-plug replacement
  • Timing-belt replacement and valve-clearance checking
  • Engine oil, filter and oil-level procedures
• S.05 – Fairings
  • Rear-view mirrors
  • Seat, tail guard and rear side body panels
  • Front mudguard procedures for the applicable customisations
  • Belly pan procedures for URBAN ENDURO
• S.06 – Electric system and engine management
  • Wiring diagrams and wiring routing tables
  • Fuse box, wire colour codes and wiring-diagram key
  • Battery, rectifier-regulator and alternator
  • Starter motor, solenoid and electric starting system
  • Lighting and headlight adjustment
  • Instrument panel, PIN CODE and immobilizer functions
  • Service indications, error warnings and displayed-error descriptions
  • ABS setting and instrument-panel functions
  • Diagnostic socket and switch checks
  • Timing/rpm, throttle-position, temperature, MAP, oil-pressure and lambda sensors
  • Stepper motor, injectors, ignition coils and electronic control unit
• S.07 – Chassis
  • Front and rear wheel removal, refitting and overhaul
  • Front and rear brake systems and brake discs
  • ABS control unit, sensors, hydraulic-system bleeding and sensor air-gap checks
  • Throttle, handlebar, clutch and gear-selector controls
  • Front fork and steering-head service
  • Rear shock absorber, suspension and swinging arm
  • Final drive, chain and sprockets
  • Footrests, side stand and frame checks
  • Tail light, number-plate holder and electrical-components compartment
• S.08 – Fuel/Exhaust system
  • Fuel tank and tank components
  • Airbox and throttle body
  • Air intake and secondary air system
  • Exhaust system and silencers
  • Canister filter system

  IMAGES PREVIEW







• S.09 – Engine
  • Complete engine removal and refitting
  • Oil pump, oil cooler and lubrication system
  • Cylinder-head checks, timing and valve-clearance work
  • Timing belts, pulleys and tensioners
  • Camshafts, valves, rocker arms and cylinder heads
  • Cylinder and piston assembly
  • Clutch and primary-drive assemblies
  • Gear-change mechanism, gearbox shafts and selector components
  • Flywheel and generator
  • Crankcase external components and crankcase halves
  • Main bearings, shaft shimming and connecting-rod assembly

Taken together, these sections provide a connected workflow from diagnosis and scheduled maintenance through component removal, inspection, measurement, adjustment and reassembly. The manual repeatedly ties procedures to the required torque settings, service limits, clearances, specified lubricants or threadlocking products and special tools, so the technician can follow both the operation and the associated service data from the same document.

Maintenance, Adjustments and Service Data

The maintenance material covers much more than a simple service checklist. The manual includes pre-delivery inspection, customer and dealer maintenance schedules, engine-oil and filter changes, oil mesh-filter cleaning, air-filter cleaning or replacement, spark-plug replacement, brake-fluid replacement, brake-pad checks, chain adjustment, steering-head adjustment, clutch and throttle free-play checks, valve-clearance inspection and timing-belt work. It also records practical values within the procedures, including a 27 ÷ 29 mm drive-chain adjustment value, opening and closing rocker-arm clearances, belt-tension checks and the tightening torques used during reassembly.

The technical-data pages also bring together fluids and capacities, wheel and suspension information, braking-system dimensions, ignition and charging information and engine service measurements. Examples include the 13.5 litre fuel-tank capacity, 3.7 litre oil-sump and filter quantity, NGK DCPR8E spark plugs, a 12 V battery and a 490 W generator. Extensive engine and frame torque tables cover fasteners across the powertrain, chassis, brakes, suspension, wheels, fuel system, exhaust and electrical assemblies.

Electrical Diagnosis, ABS and Wiring

A substantial part of the 2015 Ducati Scrambler 800 Workshop Manual – PDF Download is devoted to electrical and electronic systems. It contains wiring-diagram references, cable-colour coding, a component key and multiple routing tables that identify the physical paths of sensors, lighting, injectors, ignition components and other wiring. The manual explains the charging system, battery, electric starter, switches, instrument panel and immobilizer functions, then moves into sensor and engine-management checks.

Diagnostic coverage includes the DDS 2 diagnosis system, the diagnostic socket, displayed error descriptions and checks for components such as the timing/rpm sensor, throttle-position sensor, temperature sensor, MAP sensor, oil-pressure sensor, lambda sensors, stepper motor, ignition coils and ECU. The ABS material includes system operation, component removal and refitting, front and rear speed-sensor replacement, hydraulic-system bleeding and the specified phonic-wheel sensor air-gap procedure.

Chassis, Brakes and Running Gear

For chassis work, the manual follows assemblies through removal, inspection and refitting rather than stopping at basic adjustments. Front and rear wheel sections cover bearings, shafts, rims and, where applicable, spoke and nipple checks. Brake sections include pad replacement, discs, master-cylinder and calliper procedures, hose positioning, bleeding and ABS-related work. Steering and suspension chapters address the front fork, steering tube and bearings, rear shock absorber, swinging arm and the associated checks and tightening procedures.

The final-drive material covers chain cleaning and lubrication, chain tension, front and rear sprocket work and inspection of the chain-and-sprocket set. Frame dimensions and checks are also included, together with procedures for stands, footrests, controls and other chassis-mounted components.

Engine Disassembly and Overhaul Procedures

The engine section is one of the deepest parts of this 2015 Ducati Scrambler 800 workshop manual. It covers removal and refitting of the complete engine, lubrication components, cylinder heads, camshafts, valves and rocker arms, timing belts and pulleys, cylinders and pistons, clutch, primary drive, gearbox, generator and flywheel, crankcases, main bearings and connecting-rod assembly. Procedures include the inspection steps and measurements needed during overhaul, as well as component orientation, sealing, lubrication, tightening and special-tool references.

This depth is particularly useful when work goes beyond routine maintenance. A technician can trace a job from access and disassembly through inspection and service limits to reassembly, rather than relying on a collection of isolated specifications. The same approach applies to many chassis and electrical operations throughout the manual.

Scrambler Customisation Coverage

The manual identifies procedures and dimensions that vary across the ICON, CLASSIC, URBAN ENDURO and FULL THROTTLE customisations. These differences appear in areas such as bodywork, mudguards, wheels, exhaust components, colours and overall dimensions. Where a procedure is common to all customisations, the manual says so; where a component-specific procedure applies only to one or more versions, that distinction is shown in the relevant section.

Repair Your Ducati Scrambler 800 with the Correct Workshop Procedures

The 2015 Ducati Scrambler 800 Workshop Manual – PDF Download supports routine servicing, fault diagnosis, electrical checks, brake and ABS work, suspension and steering service, fuel and exhaust repairs, engine timing work and major engine or gearbox disassembly. Having the specified clearances, torque values, service limits, fluid information, wiring references and step-by-step procedures together matters when a repair has to be completed in the correct sequence and reassembled to the manual’s specifications.

After purchase, the manual is supplied as an instant PDF download with no physical shipping required. Open it on a computer, tablet or phone, keep it available in the workshop, and print the pages you need for a particular repair or maintenance job.
