Bucyrus 30 MB3 Operation & Maintenance Manual- CAT Continuous Miner 30 MB3 – PDF DOWNLOAD
DESCRIPTION:
Bucyrus 30 MB3 Operation & Maintenance Manual- CAT Continuous Miner 30 MB3 – PDF DOWNLOAD
General
- The 30MB3 miner is a radio-controlled drum-type continuous miner with appropriate weight balance, cutting and loading power to enable the productive mining of coal and other soft mineral in seams ranging from 1,900 mm up to 4,000 mm thick
- The machine is mounted on crawler tracks that provide full mobility and sharp turning radius in both bord and pillar and long wall development mining plans. The ranging cutting head mines material from the solid face using a chainless rotating drum, and a CLA-type gathering head with high speed conveyor efficiently moves mined material to a haulage system behind the miner.
- The machine’s weight and balance is designed to mine most efficiently by either sumping into the face at the top or bottom of the seam, and ripping material to the bottom or top of the seam
- The above figure shows a general arrangement of major mechanical components. A full description of the various major sub-systems of the 30MB3 follows.
TABLE OF CONTENTS:
Bucyrus 30 MB3 Operation & Maintenance Manual- CAT Continuous Miner 30 MB3 – PDF DOWNLOAD
MACHINE DESCRIPTION – 30MB3 ………………………………………………………………………………………………… 3
GENERAL ………………………………………………………………………………………………………………………………………… 3
SPECIFICATIONS……………………………………………………………………………………………………………………………….. 4
MACHINE WEIGHTS ………………………………………………………………………………………………………………………….. 4
COMPONENT LAYOUT ………………………………………………………………………………………………………………….. 5
TOP VIEW ……………………………………………………………………………………………………………………………………….. 5
RIGHT HAND VIEW …………………………………………………………………………………………………………………………… 6
LEFT HAND VIEW …………………………………………………………………………………………………………………………….. 7
MAIN CHASSIS …………………………………………………………………………………………………………………………………. 8
CUTTING HEAD ASSEMBLY………………………………………………………………………………………………………………… 9
GATHERING HEAD ASSEMBLY………………………………………………………………………………………………………….. 10
CONVEYOR ASSEMBLY……………………………………………………………………………………………………………………. 11
TRACTION DRIVE SYSTEM……………………………………………………………………………………………………………….. 12
HYDRAULIC SYSTEM – CLA……………………………………………………………………………………………………………… 13
MACHINE HYDRAULIC LAYOUT………………………………………………………………………………………………………… 14
DRILL RIGS ……………………………………………………………………………………………………………………………………. 16
ARTICULATING TEMPORARY ROOF SUPPORT – ATRS ………………………………………………………………………….. 17
BOLTING,MINING AND MAINTENANCE MODES…………………………………………………………………………………… 18
WATER SYSTEM……………………………………………………………………………………………………………………………… 18
WATER SYSTEM……………………………………………………………………………………………………………………………… 19
MACHINE WATER COMPONENT LAYOUT……………………………………………………………………………………………. 21
