Canon image RUNNER ADVANCE C525 /C5250/C5240/C5235 Service Manual β PDF
$38.95
Factory Service Manual for Canon imageRUNNER ADVANCE C5255 / C5250 / C5240 / C5235 multifunction printers.
Covers installation, maintenance, troubleshooting, error codes, adjustments, and disassembly procedures with full circuit and service diagrams.
Description
Canon imageRUNNER ADVANCE C5255 / C5250 / C5240 / C5235 Service Manual β PDF Download
Description
Official Canon Service Manual for the imageRUNNER ADVANCE C5200 Series (models C5255, C5250, C5240, C5235).
This detailed factory manual covers installation, maintenance, diagnostics, troubleshooting, error codes, and disassembly of all mechanical and electrical components.
Includes adjustment procedures, circuit diagrams, lubrication points, and service mode settings for professional technicians and engineers.
IMAGES:
Contents
Safety Information β Laser, toner, and high-voltage handling precautions.
Product Overview β Model differences, system configuration, engine control, and power sequence.
Theory of Operation β Image formation, laser exposure, transfer belt system, fixing and feed mechanisms, and MEAP controller interface.
Disassembly / Replacement β Step-by-step removal for assemblies (motors, PCBs, fans, rollers, sensors).
Adjustments & Calibration β Color registration, transfer roller pressure, ITB alignment, toner density, and scanner focus.
Troubleshooting & Diagnostics β
E-code error listings with description and corrective actions.
Jam detection charts and sensor location maps.
Service mode navigation and firmware update methods.
Parts & Maintenance β Preventive maintenance schedule, cleaning procedures, replacement intervals, and consumable limits.
Installation Procedures β Accessory installation, optional units (finishers, cassette decks), HDD encryption setup, and network connection.
Models Covered
Canon iR-ADV C5255 / C5250 / C5240 / C5235
Print Speed: 35β55 ppm (B/W), 30β51 ppm (Color)
Type: Color Laser Multifunction Printer
Features: Duplex printing, network MEAP, HDD encryption
Technical Highlights
| Component | Specification |
|---|---|
| Print Speed | Up to 55 ppm (B/W), 51 ppm (Color) |
| Resolution | 1200 Γ 1200 dpi |
| Processor | Canon Dual Core Controller |
| Storage | 250 GB HDD + 2 GB RAM |
| Supported OS | Windows / macOS / MEAP Systems |
| Connectivity | Ethernet, USB, MEAP, Wireless (optional) |
| Maintenance Mode | Full Service Mode Access (Service Tool v4.x compatible) |
File Details
| Parameter | Details |
|---|---|
| File Name | Β 436358977-IRAC-52xx-Service-Manual.pdf |
| Manual Title | Canon imageRUNNER ADVANCE C5255 / C5250 / C5240 / C5235 Service Manual |
| Manufacturer | Canon Inc. |
| Series | imageRUNNER ADVANCE C5200 Series |
| Document Type | Factory Service & Maintenance Manual |
| Edition / Year | Rev. 8.0 β 2014 |
| Language | English |
| Pages | ~1492 (partial extract from full ~800-page manual) |
| File Size | ~82.0 MB |
| Format | Searchable PDF (OCR Enabled) |
| Quality | Factory Original Scan |
| Delivery | Instant Digital Download |
