Case IH Maxxum 100-140 Tier 3 Service Manual 2011 – Full Workshop Manual

Description

Case IH Maxxum 100-140 Tier 3 Service Manual – 2011 Draft

This Case IH Maxxum Tier 3 service manual is the complete workshop reference for the Maxxum 100, 110, 115, 120, 125, 130 and 140 tractors, including all Multicontroller variants. Published as a draft in November 2011 under reference MAXXUM-T3-DRAFT 02/11/2011, it covers the full range of mechanical, hydraulic, electrical and electronic systems fitted to these Tier 3 machines. Whether you are diagnosing a fault, removing a major assembly, or checking a specification, this Case IH Maxxum service manual provides the procedures, values and system descriptions required to carry out the work correctly and efficiently.

File Details

• Manual Type: Service Manual (Workshop Manual)
• Brand: Case IH
• Models Covered: Maxxum 100, Maxxum 110 Multicontroller, Maxxum 110, Maxxum 115 Multicontroller, Maxxum 115, Maxxum 120 Multicontroller, Maxxum 120, Maxxum 125 Multicontroller, Maxxum 125, Maxxum 130 Multicontroller, Maxxum 130, Maxxum 140 Multicontroller, Maxxum 140
• Language: English
• Page Count: 4,200
• File Format: PDF
• Publication Reference: MAXXUM-T3-DRAFT 02/11/2011
• Document Date: November 2011

Chapters Covered

This Case IH Maxxum 100-140 Tier 3 service manual is organised into major sections, each identified by a letter and covering a group of machine functions. The full contents include:

• Section A – Distribution Systems: Primary Hydraulic Power System (A.10.A), Primary Hydraulic Power System Closed Center Mechanical Remote Valve (A.10.B), Primary Hydraulic Power System Electro-Hydraulic Remote Valve (A.10.C), Primary Hydraulic Power System Open Center Mechanical Remote Valve (A.10.D), Secondary Hydraulic Power System (A.12.A), Hydraulic Command System (A.14.A), Electrical Power System (A.30.A), Electronic System and Fault Codes (A.50.A)
• Section B – Power Production: Engine (B.10.A), Fuel and Injection System (B.20.A), Air Intake System (B.30.A), Exhaust System (B.40.A), Engine Coolant System (B.50.A), Starting System (B.80.A)
• Section C – Power Train: Power Coupling Clutch (C.10.C), Transmission Mechanical (C.20.B), Transmission Power Shuttle (C.20.C), Transmission Semi-Powershift (C.20.D), Additional Reducers Creeper (C.30.C), Additional Reducers Overdrive (C.30.D), Rear PTO Hydraulic (C.40.C), Front PTO Hydraulic (C.42.C)
• Section D – Travelling: Front Axle (D.10.A), Rear Axle (D.12.A), 2WD-4WD System Hydraulic (D.14.C), Steering Hydraulic (D.20.C), Service Brake Hydraulic (D.30.C), Parking Brake Mechanical (D.32.B), Brake Connection Hydraulic (D.34.C), Suspension Hydraulic (D.40.C), Wheels and Tracks (D.50.C)
• Section E – Body and Structure: Frame Primary Frame (E.10.B), Shield (E.20.A), User Controls and Seat (E.32.A), User Platform (E.34.A), Environment Control – Heating, Ventilation and Air-Conditioning (E.40.D)
• Section H – Hitch and Working Tool: Front Hitch (H.10.B), Rear Hitch (H.10.C), Electronic Draft Control (H.10.D)

Within these sections, the Case IH Maxxum Tier 3 service manual covers every major system on the tractor. The hydraulic sections detail the primary and secondary hydraulic power systems, including closed centre and open centre remote valve configurations, variable displacement pump operation, charge pump overhaul, compensator service, and electro-hydraulic remote valve calibration. The electrical power system section provides connector diagrams, component locations, fuse and relay specifications, charging and starting system tests, battery testing procedures, and wiring harness schematics for all model configurations. The engine section covers the fuel and injection system, air intake, exhaust, coolant system, and starting system for the Tier 3 engines.

Transmission coverage in this Case IH Maxxum workshop manual includes mechanical, power shuttle, and semi-powershift variants, along with creeper and overdrive additional reducers. Axle, brake, and steering sections give you the procedures to work on front and rear axles, hydraulic steering, service and parking brakes, and suspension systems. The hitch and working tool section covers front and rear hitches and electronic draft control, including calibration procedures for the electro-hydraulic remote valves. Introduction material covers safety rules, torque specifications, consumables, lubricants, coolants, and capacities.

How This Manual Is Organised

The Case IH Maxxum service manual uses the ICE coding system to classify technical information by location, information type, and product. Each information unit is referenced by function and information type, so you can navigate directly to technical data (specifications), functional data (how it works), diagnostic data (fault codes and troubleshooting), or service data (remove, install, adjust). This structure makes it straightforward to find the exact procedure or specification you need for any system on the Maxxum 100, 110, 115, 120, 125, 130 or 140. The manual is divided into sections and chapters, with contents pages at the beginning of each section and chapter, plus an alphabetical index at the end of every chapter.

What This Manual Enables You To Do

This complete Case IH Maxxum 100-140 Tier 3 service manual gives you the information needed to carry out major repairs, routine servicing, and accurate fault diagnosis on these tractors. The hydraulic sections cover the primary and secondary hydraulic power systems, including closed centre and open centre remote valve configurations, so you can service the pump, compensator, charge pump, and remote valves on both mechanical and electro-hydraulic systems. The electrical power system section provides detailed connector diagrams, component locations, fuse and relay specifications, charging and starting system tests, and battery testing procedures. The engine section covers the fuel and injection system, air intake, exhaust, coolant system, and starting system for the Tier 3 engines.

Transmission coverage includes mechanical, power shuttle, and semi-powershift variants, along with creeper and overdrive additional reducers. Axle, brake, and steering sections give you the procedures to work on front and rear axles, hydraulic steering, service and parking brakes, and suspension systems. The hitch and working tool section covers front and rear hitches and electronic draft control, including calibration procedures for the electro-hydraulic remote valves.

Having the correct specifications and procedures matters because these tractors use complex hydraulic and electronic systems where incorrect adjustments or assembly can lead to poor performance, damage, or unsafe operation. This Case IH Maxxum repair manual gives you the torque values, pressure settings, clearances, and step-by-step instructions that the workshop needs to get the job right the first time.

All information is presented as a PDF, so you can access it on any device, print the pages you need for the workshop, and keep the manual close at hand while working. Delivered instantly after payment, there is no shipping and no waiting. Whether you are a professional technician or a farmer maintaining your own Maxxum, this Case IH Maxxum Tier 3 service manual is the complete reference for keeping your tractor running correctly.
