Caterpillar NSV16KI Lift Trucks Operation & Maintenance Manual – PDF DOWNLOAD

DESCRIPTION:

Caterpillar NSV16KI Lift Trucks Operation & Maintenance Manual – PDF DOWNLOAD

Safety instructions
Instructions for site supervisor
• Familiarise yourself with the operating instructions and its contents.
• Train the operator on the use, safety, and maintenance aspects of the truck.
• Control that the operating and maintenance instructions, and safety regulations are observed.
Occupational safety
• Keep the truck clean and in good working order. Carry out the daily and weekly maintenance checks in
accordance with the maintenance schedule and instructions to avoid faults and operational errors.
• If you notice any faults or deficiencies that may effect the safe operation of the truck, take the truck out of
operation until the faults or deficiencies have been remedied.
• Do not repair anything on the truck without permission from the site supervisor.
• In the event of a malfunction, switch off the power and notify the site supervisor.
• When using the truck, you are responsible for both your own safety and the safety of your environment.
• Immediately notify the site supervision of any accidents or injuries. In such a case, leave the truck at the place
of the accident.
• The truck can only be used for purposes corresponding with its equipment.
Truck operator
Requirements:
• At least 18 years old
• Sufficient physical (e.g. good hearing and sight) and mental abilities for operating the truck without risks
• Appropriately trained; familiar with operating, safety and maintenance instructions
• Has permission from the site supervision to operate the truck
• Knows and masters the drive and operational features of the truck

TABLE OF CONTENTS:

Caterpillar NSV16KI Lift Trucks Operation & Maintenance Manual – PDF DOWNLOAD

WHOMM0011-01_STACKER........................................... 1
WHOMM0011-02_SAFETY_INSTRUCTIONS............................... 4
WHOMM0011-03_OPERATING_ENVIRONMENT............................. 5
WHOMM0011-04_OPERATING_DEVICES................................. 6
WHOMM0011-05_DRIVING_INSTRUCTIONS.............................. 8
WHOMM0011-06_LOAD_HANDLING.....................................10
WHOMM0011-07_BATTERIES.........................................11
WHOMM0011-08_MAINTENANCE.......................................13
WHOMM0011-09_TRANSPORTATION_AND_STORAGE........................16
WHOMM0011-10_TROUBLESHOOTING...................................17
COMBI_RO_1.23-1.25.............................................18
	Adjustment instructions....................................18
	Instructions...............................................19
COMBI_SEM-1_ENGLISH............................................21
	Index......................................................21
		1 General characteristics..............................22
			1.1  Technical specifications .....................22
			1.2  General description ..........................22
			1.3  Main features ................................22
			1.4  Safety & protection features .................23
			1.5  Thermal considerations .......................23
			1.6  Combi Sem-1 chopper diagnosis ................24
			1.7  Main Contactor and safety button  ............24
			1.8  General instructions and precautions  ........25
		2  Installation .......................................26
			2.1  Connection cables ............................26
			2.2  Contactors ...................................26
			2.3  Fuses ........................................26
			2.4  Combi Sem-1 controller mechanical drawing ....27
			2.5  Serial tiller mechanical drawing .............28
		3  Connection .........................................29
			3.1  Combi Sem-1 connection drawing ...............29
			3.2  Serial tiller connection drawing .............30
			3.3  Description of combi sem-1 connectors ........31
				3.3.1 Connector "A" description ...............31
				3.3.2 Connector "B" description ...............31
				 3.3.3 Connector "C" description ..............32
				 3.3.4 Connector "D" description ..............33
				 3.3.5 Connector "E" description ..............33
				 3.3.6 Connector "F" description ..............35
			3.4  Combi Sem-1 power connection .................35
		4  Regulation .........................................36
			 4.1  Zapi Programming handly console .............36
			 4.2  Description of standard console menu ........37
			 4.3  "Parameter Change" menu .....................38
			 4.4  "Tester" menu ...............................40
			 4.5  "Adjustment" menu ...........................40
			 4.6  "Set Option" menu ...........................40
		5  Alarms .............................................42
TH58_0800......................................................47
TH59_1004......................................................48
TS910801.......................................................49
TS1150908C_REV_E...............................................57
