Hyundai-Atlas MAXI 150SL-1 WS Waste Oil Incinerator Instruction Book

This is the full Hyundai Marine Machinery Co., Ltd. instruction book for the Hyundai-Atlas MAXI 150SL-1 WS marine waste oil incinerator, covering installation, operation, and maintenance of the complete unit as built for shipboard use. If you operate, maintain, or are responsible for compliance on a vessel fitted with this incinerator, this manual gives you the manufacturer’s own procedures rather than guesswork.

• Manual type: Instruction Book for Installation, Operation and Maintenance of Incinerator
• Brand / Type: Hyundai-Atlas Incinerator, Type MAXI 150SL-1 WS
• Manufacturer: Hyundai Marine Machinery Co., Ltd., Incheon, Korea (licensed by ATLAS A/S)
• Language: English
• Page count: 171 pages
• File format: PDF
• Revision: Update V2-20041130

Chapters Covered

• Installation & storage instructions for incinerators
• Instruction for installation (incinerator siting, diesel oil supply, sludge tank & mill pump, compressed air supply, flue gas funnel, electrical cable connection, air supply to incinerator room, fire extinguishing/SOLAS requirements)
• Description of incinerator
• Basic principles
• Working principle
• Description of process diagram (solid waste and sludge cycles)
• Technical data for incinerator
• Technical data – components (primary blower, W.O. dosing pump PU-3, primary burner ST-1, sludge burner, control panels CP-1/CP-3)
• Operating instructions
• Operating instructions for incinerator (start-up, oil sludge & solid waste charging, abnormal start-up)
• Calorific values in some waste products
• Warning
• General instructions for operation of incinerator
• Trouble shooting chart – incinerator
• Trouble shooting chart – W.O. dosing pump PU-3
• Operating instructions for digital temperature controller
• Operating instructions for flue gas temperature controller
• Operation instructions for burner control box
• Primary burner – instruction for operation and maintenance
• W.O. dosing pump (PU-3) operating and maintenance instruction
• Sludge burner
• Instruction for repair of refractory lining
• Scheme for maintenance
• Lubrication scheme
• Component drawing & list of components
• Parts list for primary burner
• Parts list for W.O. dosing pump
• Parts list for sludge burner
• Instructions for operation of mill pump (PU-5)
• Technical data – Mill pump (PU-5)
• Parts list for PU-5

Together, these sections take a technician from correctly siting and connecting the MAXI 150SL-1 WS through daily start-up, sludge and solid-waste charging cycles, alarm/safety interlock response, and right down to lubrication scheduling and refractory lining repair — everything needed to keep the unit compliant with MARPOL Annex V and running reliably at sea.

Technical Data Highlights

• Calorific capacity: 700,000 Kcal/H (814 Kw)
• Solid waste capacity: max. 150 Kg/H (2,400 Kcal/Kg)
• Liquid waste capacity: max. 82 Kg/H (8,600 Kcal/Kg)
• Flue gas retention time: 1 second; flue gas volume approx. 16,700 M3/H at 350°C
• Power source: AC 440V, 60Hz, 3-phase; control source AC 220V, 60Hz, 1-phase
• Primary burner: type DH 160 E2, oil pump BFP 21 L5, marine diesel oil, 17 L/H capacity
• W.O. dosing pump PU-3: type MD 012-12, 26–137 L/H at 72–380 RPM
• Primary blower: HTF-#3 1/2 type, 6,600 M3/H, 22 Kw x 2P motor, 3500 RPM
• Rule compliance: DNV, IMO Type Approval Cert. (MARPOL 73/78 Annex V guidelines), MED 96/98/EC

IMAGES PREVIEW

Why Technicians and Ship Operators Rely on This Manual

The Hyundai-Atlas MAXI 150SL-1 WS Instruction Book gives you the manufacturer’s exact set points for pre-purge timing, combustion chamber temperatures, alarm limits (fire, flame failure, low pressure cooling air, high flue gas temperature, motor overload), and component specifications for the primary blower, sludge pump, primary burner, and sludge burner. Working from the correct procedures and set points reduces the risk of nuisance shutdowns, out-of-spec emissions, or damage to the refractory lining, and keeps documentation ready for classification society and port state inspections.

This Hyundai-Atlas MAXI 150SL-1 WS manual is delivered as an instant PDF download — no shipping, no waiting. Read it on a laptop, tablet, or phone in the engine room, or print the pages you need for a quick-reference binder alongside the incinerator control panel.
