Ingersoll-Rand SD-100B SD-100DB SD-100FB Vibratory Compactor Parts Manual 2000

Description

Ingersoll-Rand SD-100B Series Parts Manual – PDF

This is the Ingersoll-Rand parts manual for the SD-100B, SD-100DB and SD-100FB vibratory compactors, published May 1, 2000. It applies to all SD-100B series machines effective with serial number 158436, and it also covers serial number 157637. The manual is built around two lookup systems: a Word Index in the back that finds a part from any functional word in its description, and a Numerical Index that finds a page from a known Comm. Number. Every parts identification page pairs an exploded illustration with a matching parts list broken down by Item Number, Comm. Number, description, quantity and any extra notes or dimensions needed to place an order.

File Details

• Manual type: Parts Manual (Parts Catalog)
• Brand: Ingersoll-Rand
• Models covered: SD-100B, SD-100DB, SD-100FB
• Serial coverage: Effective with S/N 158436, including S/N 157637
• Language: English
• Page count: 324 pages
• File format: PDF
• Publication date: May 1, 2000
• Publisher: Ingersoll-Rand Company, Shippensburg, PA

Chapters Covered

The manual is split into Functional Groups identified by capital letters, and each group is further divided into numbered sections.

• A – Axle & Main Frame: Axle and Wheel Installation; Main Frame Assembly (effective with S/N 160281); Main Frame Assembly (prior to S/N 160281); Fender Installation; Railing Installation; ROPS/FOPS Installation; No ROPS Installation (optional); FOPS Stowage Installation (optional); Vandal Cover Installation (optional); Vibrating Reed Tachometer (optional); Cab Installation (optional); Cab Heater Installation (optional); Cab Kit Assembly; Cab Heater & Air Conditioning Installation (optional); Cab ROPS Installation (optional); Canopy Installation (optional).
• B – Drum: Drum and Swivel Installation; Drum Assembly (SD-100B/DB); Drum Assembly (SD-100FB); Shock Mount Assembly (Drive Side) SD-100B; Shock Mount Assembly (Drive Side) SD-100DB; Shock Mount Assembly (Carrier Side); Carrier and Eccentric Assembly; Eccentric Assembly – Driven Side; Eccentric Drive Shaft Assembly; Drum Drive Assembly (SD-100FB); Heavy Duty Torque Hub with Drum Drive Assembly (SD-100DB, optional); Bolt-On Padfoot Shell Installation (SD-100DB); Heavy Duty Torque Hub Installation (SD-100FB, optional); Shock Mount Assembly – Drive Side (SD-100FB, optional).
• C – Engine: Engine Installation (SD-100B, effective with S/N 167787); Engine Installation (SD-100B, prior to S/N 167787); Engine Installation (SD-100DB); Engine Installation (SD-100FB); EPA Engine Installation (SD-100DB/FB, optional); Propulsion Pump Assembly (SD-100B); Propulsion Pump Assembly (SD-100DB/FB); Vibration Pump Assembly; Steering Pump Assembly; Pump Control Assembly; Engine Cowling and Radiator Installation; Fuel Lines Installation; Throttle Installation; Air Cleaner Installation; Suction Filter Assembly; Charge Filter Assembly; Air Pre-Cleaner (optional); Block Heater Installation (optional); Cold Start Kit (optional); Grid Heater for EPA Engine Installation (optional).
• D – Console: Operators Platform Installation; Steering and Horn Installation; Seat and Safety Manual Installation; Steering Knob Installation (optional).
• E – Electrical: Wire Harness Installation; Battery Installation; Back-Up Alarm Installation; Turn Signal/Hazard Warning Light Installation (optional); Flood Light Installation (optional); Compactometer Installation (optional).
• G – Decals and Paint: Decal Installation, including crush-area, throttle, operation warning, ROPS hazard, grease, rail warning, lube chart, pressure hazard, model and ignition switch decals, plus paint codes.
• H – Hydraulics: Traction Hosing Installation (SD-100B); Traction Hosing Installation (SD-100DB/FB); Vibration Hosing Installation (SD-100B); Vibration Hosing Installation (SD-100DB/FB); Steering Hosing Installation; Brake Hosing Installation; Filter Hosing Installation; Strike-Off Blade Installation and Assembly (SD-100FB, optional); Cylinder Support Assembly (SD-100FB, optional); Strike-Off Blade Valve Installation (SD-100FB, optional); Hydraulic Oil Temperature Gauge Installation (optional).
• I – Internal Breakdowns: Axle Assembly (59179010); Axle Drive Motor (59012104) SD-100B; Axle Drive Motor (59182063) SD-100DB/FB; Cab Assembly (59246579); Eccentric Drive Motor (59539692); Drum Drive Motor (59054791) SD-100DB; Torque Hub (59762609) SD-100B; Torque Hub (59040659) SD-100DB; Drum Drive Motor (59161661); Propulsion Pump (59396499); Drum Drive Motor (58977620) SD-100FB; Torque Hub (58952573) SD-100FB; Propulsion Pump (59313205) SD-100B; Propulsion Pump (59068874) SD-100DB; Vibration Pump (59090605); Seat (59340133); Control Lever (59815449); Compactometer Kit (59181735); Strike-Off Blade Control Valve (59621623).
• M – Maintenance Interval Kits: 250-Hour kit part numbers and contents.
• P – Publications and Training: Manual list for the SD-100B series.
• W – Word Index and X – Numeric Index for cross-referencing part descriptions and Comm. Numbers.

Put together, these groups give a technician a complete map of the SD-100B series machine. Every major assembly is broken down to its serviceable parts, with the fasteners, O-rings, seals, shims, bearings and adapters that go with it. Because the breakdowns are organized by Comm. Number, the same part can be traced from the top-level installation down into the internal component it lives in, so a shop can order the exact seal kit or bearing for a pump or torque hub rather than replacing the whole unit. The hosing and piping sections list individual hose assemblies with their lengths, and the decal chapter covers the safety and information placards that keep a machine compliant.

What This Parts Manual Helps You Do

With this manual on hand, a workshop or owner can rebuild the drum drive, eccentric drive, propulsion pump, torque hub and axle assemblies to component level instead of guessing at part numbers. The Internal Breakdowns section alone covers the axle assembly, axle drive motors, cab assembly, eccentric drive motor, drum drive motors, torque hubs, propulsion pumps, vibration pump, seat, control lever, compactometer kit and the strike-off blade control valve. Every one of those assemblies is shown in exploded form with each piece numbered and matched to a Comm. Number in the adjacent list. That level of detail is what turns a vague repair estimate into a confirmed parts order.

The hydraulic hosing chapters are just as practical. Traction, vibration, steering, brake and filter hose routings are split by model, so there is no confusion between an SD-100B and an SD-100DB or SD-100FB layout. The optional strike-off blade section on the SD-100FB is broken out with its own cylinder, valve, cylinder support and control lever parts, which matters if the machine was ordered with that attachment.

Decals, paint codes and the maintenance interval kits round out the document. The 250-hour kit listing lets a fleet manager pre-stage the correct filters in one part number instead of chasing six separate lines, and the decal list carries the model, throttle, grease, hydraulic oil, diesel fuel, roll-over and pressure hazard placards that keep a machine safe and compliant on a job site.

Why Correct Part Numbers Matter on the SD-100B Series

The SD-100B, SD-100DB and SD-100FB share a lot of architecture, but they do not share every part. Axle drive motors differ between the SD-100B and the SD-100DB/FB. Propulsion pumps split three ways. Drum drive motors change depending on whether the machine has the heavy duty torque hub option or the bolt-on padfoot shell. Serial number breakpoints such as 167787, 160281, 166777, 167629, 167887, 168501, 163599, 169126, 161687, 161693, 158713, 159748 and 166127 each change which part is correct for a given machine. Ordering by eye, or by memory, is how the wrong seal kit or the wrong hose assembly ends up on the shelf. This manual ties every one of those changes back to the Comm. Number that matches the machine in front of you.

IMAGES PREVIEW

Instant PDF Delivery

The file is delivered as an instant PDF download after payment. No shipping, no waiting, no physical binder to lose on the shop floor. Open it on a laptop at the bench, on a tablet next to the machine, or print the pages you need for the job at hand. The full Word Index and Numerical Index make it fast to jump straight to the correct illustration and part list, whether you are looking up a part by name or by the Comm. Number printed on the old component.
