Lexmark X543, X544, X546 Color Laser MFP Service Manual & Parts List PDF
Original price was: $120.00.$18.95Current price is: $18.95.
Official Lexmark Factory Service Manual for the X543, X544, and X546 Series MFPs. This massive technical suite provides professional-grade diagnostics, detailed removal/installation procedures, and a comprehensive illustrated parts catalog. Includes step-by-step guidance for fuser assembly removal, printhead service checks, and ADF paper jam troubleshooting to keep your Lexmark color laser MFP running at peak performance.
Description
Lexmark X543, X544, X546 Color Laser MFP Service Manual & Parts List PDF DOWNLOAD
DESCRIPTION
Maintain the professional quality of your office output with the Official Lexmark X543, X544, X546 Series Service Manual. This digital publication is the definitive resource used by certified field engineers to diagnose, repair, and service these high-performance color laser multifunction printers.
Whether you are performing a complex fuser drive motor assembly removal or navigating the Lexmark diagnostics menu to resolve a networking service check error, this manual provides the precise factory data and high-resolution diagrams required for a “First Time Right” repair.
Technical Sections & Bookmarks:
General Information: Models covered, features, power/electrical specifications, and media handling guidelines.
Diagnostic Information:
POR (Power-On Reset) sequence diagnostics.
Symptom Tables: Detailed workflows for “Dead printer,” print quality, and scan/fax/copy issues.
Error Codes: Complete dictionary of User Status Messages, Paper Jam messages (2xx), and Service Error codes (1xx, 8xx, 9xx).
Diagnostic Aids: Procedures for registration, color plane alignment, hardware tests, and scanner sensor tests.
Repair Information: * Print Engine Removal: Detailed steps for covers, controller board removal, fuser, and high-voltage power supply (HVPS) .
Scanner Removal: Flatbed, Duplex ADF, and operator panel assembly instructions .
Parts Catalog: Illustrated exploded views and part numbers for all field replaceable units (FRUs) across seven major assemblies .
Quick Reference Hardware Specifications:
| Feature | Lexmark X543 | Lexmark X544 | Lexmark X546 |
| Max Resolution | 1200 dpi / 4800 CQ | 1200 dpi / 4800 CQ | 1200 dpi / 4800 CQ |
| Scan Speed (ADF) | Up to 5 ppm (Simplex) | Up to 5 ppm (Duplex) | Up to 5 ppm (Duplex) |
| Duty Cycle Component | Fuser/ITU: 60k pages | Fuser/ITU: 60k pages | Fuser/ITU: 60k pages |
| Max Memory | 640 MB | 640 MB | 640 MB |
FILE DETAILS
Manual Name: Lexmark X543, X544, X546 Service Manual
Models Covered: X543dn, X544n, X544dn, X544dw, X544dtn, X546dtn
Year / Edition: September 8, 2009 (7525-xxx)
Manual PDF Quality: Professional Factory Original, Searchable & Indexed
No. of Pages: 351 Technical Pages
โก INSTANT REPAIR ACCESS
Don’t let a “Service Call” stop your business in its tracks. Purchase this manual now to instantly download the factory secrets and high-resolution schematics needed to fix your Lexmark MFP today!
