Liebherr LR 1600-2 Crawler Crane Operating Instructions Manual 18112-01-02

Description

Liebherr LR 1600-2 Crawler Crane Operating Instructions Manual

This is the complete operating instructions manual for the Liebherr LR 1600-2 and LR 1600-2-W crawler cranes, published under document number 18112-01-02. At 2038 pages, it is the full factory-issued reference covering every stage of the crane’s working life – from initial planning and assembly through daily operation, boom configuration, maintenance, and recurring inspections.

The Liebherr LR 1600-2 is a heavy-lift crawler crane built for large-scale lifting operations, and this manual reflects that scale. It documents the crane’s crawler travel gear, turntable, boom systems, derrick ballast arrangements, ballast trailer, and the LICCON computer system that monitors and controls the machine. Every chapter is structured the way Liebherr-Werk Ehingen issued it, so the procedures, danger notes, and load-chart references match the crane as built.

File Details

• Manual type: Operating Instructions
• Brand: Liebherr
• Model: LR 1600-2 / LR 1600-2-W
• Document number: 18112-01-02
• Language: English
• Page count: 2038
• File format: PDF
• Issuing works: Liebherr-Werk Ehingen GmbH
• Copyright: Liebherr-Werk Ehingen GmbH 2015

Chapters Covered

The manual is organized into nine top-level chapters, each carrying its own numbered sub-sections. The contents below reflect the actual chapter headings printed in the document.

• 1 Description of crane – terminology, component overview, boom systems, product description, technical data, dimensions and weights, load handling equipment, ground pressure, noise emission, vibrations, crane speeds, ropes
• 2 Safety – job planning, general safety technical guidelines, danger zone of crane, traffic endangerment, air traffic, movement on the crane, emergency exit, personal protective equipment, securing persons, rescuing assembly personnel, crane cab with retractable step, crane cab with incline adjustment, safety bar, closing windows, rigging and fastening points, heated crane components, crane operator responsibilities, selecting the operating site, slopes and ditches, load burdens on the ground, support, aligning the crane, checking safety measures, external power supply, grounding, transmitters, thunderstorms, wind influences, lifting with two cranes, working ranges overlap, hand signals, crane operation with a load, lifting of personnel, securing personnel on shut off crane, welding work on the load, travel and crane operation, ladders, signs on the crane, labeling of load lifting equipment, antifall guards, working in low temperatures, ballast trailer operation
• 3 Crane assembly – crawler carrier assembly, turntable assembly, central ballast, mechanical auxiliary support, SA bracket assembly, assembly conditions, assembly hoist winches
• 4 Operation of crane superstructure – operating and control instruments, LICCON computer system, crane start up and taking the crane out of service, safety equipment, crane operation, rope reeving, counterweight, working with a load, driving from the crane operator’s cab, procedure for shut off of crane movements
• 5 Equipment – safety technical notes for assembly and disassembly, SA-frame, boom systems, D-boom, SW/SDW boom combination, WV-lattice jib, boom nose lattice boom, SLF-boom combination, pulley set, SWF-boom combination, hook blocks, pin pulling device, derrick ballast – ballast trailer, derrick ballast – suspended ballast, S/SL/HS/HSL boom, SD/SLD/HSD/HSLD boom combination, pulley cart
• 6 Additional equipment – heater / engine preheating / air conditioning system crane operator’s cab, emergency take-down
• 7 Service and maintenance – maintenance and service general, maintenance intervals crawler chassis, maintenance intervals ballast trailer, maintenance intervals crane superstructure, maintenance intervals crane boom, maintenance guidelines crane chassis, maintenance guidelines crane superstructure, fill quantities, lubrication schedule, service fluids and lubricants, procedure in case of problems
• 8 Inspections of cranes – periodic crane inspections, inspection of winches, inspection of crane wire ropes, inspection of load hooks, inspection of hydraulic hose lines, inspection of safety switching on the relapse supports, inspection of accumulator pressure in relapse cylinder, inspection of guy rods, inspection of ladders, inspection chart for cranes
• 90 Attachment – foreword to attachment, update confirmation

What this gives a technician is the complete authorized procedure set for the LR 1600-2. The safety chapter alone runs to dozens of sub-sections covering danger zones, wind limits, hand signals, working near transmitters, and low-temperature operation. The crane assembly chapter documents how the crawler carriers, turntable, central ballast, and SA-frame go together. The equipment chapter covers every boom system the crane can be configured with – S, SL, HS, HSL, SW, SDW, SDWV, SLF, SWF, SD, SLD, HSD, HSLD, and the WV-lattice jib – along with their assembly, guy rod, and electrical connection procedures. The maintenance chapters give inspection intervals and service guidelines for the crawler chassis, crane superstructure, and boom, and the inspection chapter documents what an authorized inspector must check on wire ropes, load hooks, guy rods, ladders, and hydraulic hose lines.

Safety Systems and LICCON Coverage

A substantial portion of the manual is devoted to the safety systems and the LICCON computer system. The overload protection (LMB), hoist limit switches (HES1, HES2, HES3), boom limitation, advance warning, and STOP functions are documented in detail, including the exact procedures for resuming crane movements after a shut off. The manual explains how to bypass the hoist top shut off, how to exceed shut off limits of the LICCON overload protection during erection and take down, and how the emergency operation of the LICCON overload protection works on cranes with and without a CE mark.

Winch assignments, pulley head selection, hook block weight entry, derrick ballast radius and weight entry, and the various operating screens are all documented. The manual also covers the LICCON Job Planner references where they appear in the crane’s own operating logic.

Boom Systems and Ballast

The boom system chapter is one of the largest in the manual. It documents the S main boom, SL main boom with light lattice sections, HS heavy main boom, HSL heavy main boom with light lattice sections, W luffing jib, F fixed jib, D derrick boom, and the various combinations – SDBW/B, SLDB/BW, SL2DBW/B, SDWBW/B, SDWVB/BW, SL2DFB/BW, SL4DFB/BW, SL5DFBW/B, SL10DFB/B2, SL11DB/B2, SL13DFB/B2, SL14DB/B2, HSDBW/B, HSLDB/BW, HSL2DBW/B, HSDWBW/B, HSDWVB/BW, HSL2DFB/BW, HSL4DFB/BW. Each combination is documented with its assembly, pinning, guy rod, and erection procedures.

Derrick ballast is covered in two full chapters – one for the suspended ballast configuration and one for the ballast trailer. The manual documents the ballast pallet, suspended ballast guide, ballast trailer guide, pull cylinders, support cylinders, and the LICCON displays for derrick ballast radius, weight, and utilization. The differential force monitoring for derrick ballast guying is also documented.

Inspection and Maintenance Reference

The maintenance and inspection chapters give this manual long-term value beyond initial assembly. The maintenance intervals for the crawler chassis, ballast trailer, crane superstructure, and crane boom are laid out in schedules that combine operating-hour and calendar intervals. The inspection chapter documents the periodic crane inspection requirements, including what an expert or authorized inspector must check on carrying crane structures, rope feed mechanisms, locking systems, safety ropes, load handling equipment, fastening equipment, membrane accumulators, relapse cylinders, rope pulleys, carrier rollers, sliding beams, overload protection, roller slewing ring connections, and load bearing equipment mountings.

The crane wire rope inspection chapter is particularly detailed, covering removal criteria, broken wire counting, diameter reduction, corrosion, corkscrew-like distortion, basket formation, loop formation, kinking, buckles, heat effects, and combined degree of severity – all according to the standards the manual references.

What This Manual Enables You to Do

With the Liebherr LR 1600-2 operating instructions manual on hand, you can carry out the full range of tasks the crane was designed for: assemble and disassemble the crawler carriers, turntable, central ballast, and boom systems; configure the crane for S, SL, HS, HSL, SW, SDW, SDWV, SLF, SWF, SD, SLD, HSD, and HSLD operation; set up derrick ballast as suspended ballast or ballast trailer; operate the crane from the crane operator’s cab using the LICCON computer system; carry out load lifts with the correct load chart, reeving, and counterweight; and perform the maintenance and inspection routines that keep the crane safe and available.

Correct procedures and specifications matter on a crane of this size. The manual gives you the actual danger notes, the actual load chart references, the actual LICCON screen logic, and the actual inspection criteria that Liebherr-Werk Ehingen issued for this machine. Working from the manual rather than from memory or guesswork is what keeps the crane, the load, and the crew safe.

IMAGES PREVIEW

The manual is delivered as an instant PDF download after payment. There is no shipping, no waiting, and no physical book to keep track of. You can open it on any device – laptop, tablet, or phone – and print the pages you need for the job site or the workshop. Whether you are rigging the crane for a lift, diagnosing a LICCON error, planning a boom configuration, or preparing the crane for its next periodic inspection, the LR 1600-2 operating instructions are the reference you want within reach.
