Piper Cherokee PA-32-260 PA-32-300 PA-32R-300 Parts Catalog Manual (753 689)

Description

Overview of the Piper Cherokee PA-32-260 PA-32-300 PA-32R-300 Parts Catalog Manual (753 689)

The Piper Cherokee PA-32-260 PA-32-300 PA-32R-300 Parts Catalog Manual (753 689) provides an exhaustive, fully illustrated guide to identifying and ordering replacement components for Piper Cherokee Six and Lance aircraft. Originally issued by the Piper Aircraft Corporation on June 27, 1975, and updated through the April 1980 revision, this master parts catalog encompasses fixed-gear and retractable variants across extensive production model runs. Whether you are maintaining a classic fixed-gear Cherokee Six 260, operating a heavy-hauling Cherokee Six 300, or managing a retractable-gear PA-32R-300 Lance, this publication delivers positive part identification, assembly hierarchies, and commercial hardware specifications essential for professional aircraft maintenance.

File Details

• Manual Type: Illustrated Parts Catalog (Aerofiche Card 1 Master File)
• Manufacturer / Brand: Piper Aircraft Corporation
• Applicable Aircraft: Piper Model PA-32-260, PA-32-300, PA-32R-300 Cherokee, and PA-32S-300 Seaplane
• Publication Part Number: 753 689 (753-689)
• Revision Status: Revised April 1980 (Supersedes prior revisions PR751031, PR760412, PR760917, PR770223, PR770909, PR780113, PR781106)
• Language: English
• Total Page Count: 636 pages
• Document Format: High-quality digital PDF (.pdf)

Comprehensive Model & Serial Number Coverage

This Piper Cherokee PA-32-260 PA-32-300 PA-32R-300 Parts Catalog Manual (753 689) contains explicit serial number applicability grids to guarantee exact part ordering across successive design updates. The detailed listings cover:

• Piper PA-32-260: Serial numbers 32-1 through 32-1110
• Piper PA-32-260 'B' Models: Serial numbers 32-1111 through 32-1250
• Piper PA-32-260 'C' Models: Serial numbers 32-1251 through 32-1320
• Piper PA-32-260 'D' Models: Serial numbers 32-7100001 through 32-7100038
• Piper PA-32-260 'E' Models: Serial numbers 32-7200001 through 32-7200055
• Piper PA-32-260 Annual Production: 1973 (32-7300001 to 32-7300076), 1974 (32-7400001 to 32-7400061), 1975 (32-7500001 to 32-7500053), 1976 (32-7600001 to 32-7600033), 1977 (32-7700001 to 32-7700023), and 1978 (32-7800001 to 32-7800008)
• Piper PA-32-300: Serial numbers 32-40000 through 32-40565
• Piper PA-32-300 'B' Models: Serial numbers 32-40566 through 32-40850
• Piper PA-32-300 'C' Models: Serial numbers 32-40851 through 32-41018
• Piper PA-32-300 'D' Models: Serial numbers 32-7140001 through 32-7140086
• Piper PA-32-300 'E' Models: Serial numbers 32-7240001 through 32-7240147
• Piper PA-32-300 Annual Production: 1973 (32-7340001 to 32-7340201), 1974 (32-7440001 to 32-7440182), 1975 (32-7540001 to 32-7540198), 1976 (32-7640001 to 32-7640142), 1977 (32-7740001 to 32-7740113), 1978 (32-7840001 to 32-7840222), and 1979 (32-7940001 to 32-7940282)
• Piper PA-32R-300 Lance: 1976 (32R-7680001 to 32R-7680538), 1977 (32R-7780001 to 32R-7780549), and 1978 (32R-7880001 to 32R-7880068)
• Piper PA-32S-300 Seaplane: Specific coverage for float-equipped models (serial numbers 32S-40000 through 32S-7240147)

Chapters Covered

• Introductory & General Data: Aerofiche structure, revision control, parts ordering procedures, indentured assembly hierarchy, and serial number effectivity schedules
• Factory Paint Specifications: Standard paint reference charts for Acrylic Lacquer and DuPont Imron Polyurethane Enamel and Primers with factory color codes and Piper part numbers
• Section I — Wing Group: Figure 1 View of Complete Airplane; Figure 2 Wing Installation; Figure 3 Wing Leading Edge Assembly (PA-32-260 S/N 32-1 & up, PA-32-300 S/N 32-40000 to 32-7840222); Figure 3A Wing Leading Edge Assembly (PA-32-300 S/N 32-7940001 & up, PA-32R-300 S/N 32R-7680001 & up); Figure 4 Wing Trailing Edge Assembly (PA-32-260/300); Figure 5 Wing Trailing Edge Assembly (PA-32R-300); Figure 6 Flap Assembly; Figure 7 Aileron Assembly
• Section II — Fuselage Group: Figure 8 Complete Fuselage; Figure 9 Upper Forward Cockpit Assembly (PA-32-260/300); Figure 10 Upper Forward Cockpit Assembly (PA-32R-300); Figure 11 Upper Center Cockpit Assembly; Figure 12 Upper Aft Cockpit Assembly; Figure 13 Lower Forward Cockpit Assembly; Figure 14 Lower Aft Cockpit Assembly; Figure 15 Fuselage Aft Section; Figure 16 Enclosure Installation (early serial blocks); Figure 17 Enclosure Installation (1973 model blocks); Figure 18 Enclosure Installation (1974 & later blocks, including PA-32R-300); Figure 19 Forward Cabin Door (early through 1976 blocks); Figure 19A Forward Cabin Door (1976 & later blocks); Figure 20 Aft Cabin Door; Figure 21 Forward Baggage Door; Figure 22 Aft Cargo Door (early through 1973 blocks); Figure 23 Aft Cargo Door (1974 & later blocks); Figure 24 Cockpit Finishing Installation; Figure 24A Window Curtains Installation; Figure 25 Carpet Installation
• Additional Master Catalog Groups (Card 1 Index Outline): Section III Tail Surfaces Group; Section IV Chassis Group; Section V Hydraulic Group; Section VI Power Plant Group; Section VII Fuel System Group; Section VIII Control System Group; Section IX Electrical System Group; Section X Electronics Group; Section XI Miscellaneous Group

By organizing every airframe assembly into exploded isometric technical drawings paired with itemized part breakdown tables, this parts catalog gives aircraft owners, certified technicians, and parts managers an exact roadmap of the airframe. The indented nomenclature clearly indicates component-to-subassembly relationships, distinguishing whole structural assemblies from individual ribs, doublers, skins, latches, and attaching commercial hardware.

Airframe Structural Subassemblies & Parts Breakdowns

Within the Piper Cherokee PA-32-260 PA-32-300 PA-32R-300 Parts Catalog Manual (753 689), every structural assembly is meticulously broken down. For the wing group, users can trace the complete inboard, center, and outboard leading edge skins, main spars, rear spars, false spars, flap hinge brackets, and aileron balance weights. Specialized differences between the fixed-gear PA-32 wings and the wheel-well cutouts, gear door hinges, and trunnion supports of the retractable PA-32R-300 Lance are thoroughly cataloged with discrete part numbers.

Fuselage structural coverage extends through all upper and lower cockpit stations, bulkheads at station 49.5, 73, 85, 108, 128, 165, and 187, as well as tail cone attachment fittings and stabilator pulley supports. Door assemblies are extensively covered across multiple design generations, detailing the early and late forward cabin doors, aft passenger door, forward nose baggage door, and the wide rear utility cargo door with internal mechanical latch linkages, striker plates, and holding sockets.

IMAGES PREVIEW

Interior Appointments, Hardware & Enclosures

This parts catalog details every internal cockpit trim component, including instrument panel shock mounts, control wheel bushings, fresh air ducting, overhead vents, and floorboard structures. The enclosure installation figures itemize standard and heavy .250-inch sound-reduction windshields, tinted and clear side windows, and storm window latch assemblies. The interior finishing sections provide full color code breakdowns for side trim panels, armrest housings, window trim extrusions, curtains, and cabin carpets across red, blue, brown, black, green, fawn, monaco, heather, and bark color schemes.

Notice Regarding Rigging and Installation

As explicitly specified by the Piper Aircraft Corporation within the introduction of this catalog: Under no circumstances shall this catalog be used for rigging and installation purposes. Structural adjustments, rigging procedures, cable tensions, and torque specifications are detailed in the official Piper PA-32 Service Manual. This publication is engineered specifically for positive identification, inventory verification, and ordering of airframe components and hardware.

Why This Parts Catalog Is Essential For Your Piper PA-32 Fleet

Maintaining airworthiness and undertaking structural repairs requires exact part numbers and visual confirmation of component assemblies. The Piper Cherokee PA-32-260 PA-32-300 PA-32R-300 Parts Catalog Manual (753 689) eliminates costly guesswork when purchasing replacement parts, sourcing standard AN, MS, and NAS attaching hardware, or verifying airframe configuration history. Available as an instant PDF download, this digital catalog provides immediate access on desktop, laptop, tablet, or mobile phone, without shipping delays or worn paper pages. You can zoom in on intricate exploded drawings or print crisp hard copies for work right at the aircraft hangar workbench.
