The Piper PA-28 & PA-28R Cherokee Illustrated Parts Catalog 753-582 – 2013 PDF is an extensive illustrated reference for identifying replacement parts used on the PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-235, PA-28R-180 and PA-28R-200. Piper describes the catalog as providing positive identification of replacement parts, with individual sections combining illustrations and corresponding parts listings. The catalog was reissued April 10, 2013 under Part Number 753-582.

This is a particularly detailed reference because part identification is tied not only to illustrated assemblies but also to aircraft model and serial-number effectivity. Listings use figure and index numbers, Piper part numbers, application codes, nomenclature, quantity required and serial numbers affected. Assembly relationships are shown through indentation in the nomenclature listings, allowing a user to follow a complete assembly down to the components grouped beneath it.

File Details

• Manual type: Illustrated Airplane Parts Catalog
• Brand: Piper Aircraft
• Models: PA-28-140, PA-28-150, PA-28-160, PA-28-180, PA-28-235, PA-28R-180, PA-28R-200
• Language: English
• Page count: 1024 pages
• File format: PDF
• Part number: 753-582
• Reissued: April 10, 2013

Illustrated Parts Identification and Serial-Number Effectivity

The Piper PA-28 and PA-28R Cherokee parts catalog is structured for finding a component from its location and appearance, then matching the illustration index to the corresponding parts list. The catalog explains that the part-number column identifies the replacement part, while the nomenclature column supplies its name and the quantity column shows the number used in the figure or assembly. Application codes identify special uses, and the serial-number column distinguishes which aircraft a particular part applies to.

That model and serial-number detail is important across a catalog covering numerous Cherokee production configurations. Separate figures and listings are provided where installations differ between fixed-gear PA-28 aircraft and PA-28R models, and many later assemblies are divided further by serial number. The introductory material also explains the serial-number formats used before the 1971 model year and the four-part system used for 1971 and subsequent model years.

The catalog also discusses alternate Piper part-number formats. Part numbers may appear with different suffix formatting, and the text explains that some production-number forms can be superseded or replaced by service-number forms. This makes the catalog useful when comparing an existing component, an illustration callout and the associated service part listing.

Important: the catalog specifically states that it is not to be used for rigging and installation purposes. Its role is illustrated replacement-parts identification and application reference rather than a substitute for the applicable maintenance or installation instructions.
