Volvo EC15B Type 272 XR Compact Excavator Parts Catalog – VOE 6444410017 PDF

Description

Volvo EC15B Type 272 XR Parts Catalog

This is the complete illustrated parts catalog for the Volvo EC15B Type 272 XR compact excavator, identified by catalog number VOE 6444410017 (Catalogue id 10017). It covers the basic machine 272.10151 EC15B XR and lists genuine part numbers, quantities, descriptions and exploded-view illustrations for every major assembly on the machine. Text is presented in English, French, German and Spanish side by side, making it usable across multilingual workshops and parts counters.

File Details

• Manual type: Illustrated Parts Catalog
• Brand: Volvo Construction Equipment
• Model: EC15B Type 272 XR
• Basic machine: 272.10151 EC15B XR
• Catalog number: VOE 6444410017
• Catalogue id: 10017
• Language: English / French / German / Spanish
• Page count: Approx. 447 pages
• File format: PDF

Chapters Covered

• Group 1 – Preface and Instructions
• Group 2 – Engine (210-275)
  • Equipped engine L3E2-64ESA / L3E-W264ESA
  • Engine gasket kit
  • Cylinder head, cylinder block, flywheel housing
  • Pistons, rocker arm shaft, timing gear casing, timing gears, camshaft
  • Connecting rods, lubrication oil sump, engine mounts
  • Lubricating oil pump, oil filter
  • Fuel pump, fuel filter, sediment bowl, gas-oil tank
  • Fuel circuit, injection pump, injector
  • Exhaust manifold, intake manifold, muffler, catalytic exhaust
  • Intake / air filter, preheating coil
  • Radiator (water), expansion tank, cooling circuit, radiator installation
  • Water pump, thermostat
  • Engine stop electromagnet, engine acceleration control
• Group 3 – Electrical (311-393)
  • Battery, alternator installation, alternator 12V – 40A
  • Starter motor installation, starter motor 12V – 1.6KW
  • Starting and preheating switch, coded keypad (anti-start)
  • Front headlight on canopy, front headlight on cab, rear headlight
  • Work light on boom, horn, flashing light
  • Cleaning system, oil pressure switch, clogging indicator, thermal switch
  • Operator’s station instrument panel (right and left)
  • Inspection light socket
  • Electrical system / without Puma, / Canopy, / cab, / battery
  • Electrical equipment / without Puma, battery cut-out
  • Transmitter, control panel, radio kit
• Group 4 – Power Train (415-492)
  • Engine coupling / hydraulic pump
  • Travelling gear motor assy / without brake
  • Hydraulic travelling motor
  • Balancing valve (travelling)
  • Slewing gear motor installation, slewing gear motor
  • Swivel joint equipment, swivel joint
  • Slewing ring, lubrication
• Group 7 – Frame and Crawler Unit (716-775)
  • Counterweight
  • Lower frame (narrow and wide)
  • Platform
  • Track tensioning (rubber tracks)
  • Travelling gear motor assy / sprocket
  • Rubber tracks
  • Lower roller (rubber tracks)
• Group 8 – Body with Associated Parts (810-897)
  • Equipped cabin, cab framework, cab sliding window (front)
  • Canopy, wind protector
  • Engine coverage
  • Cab door, cab glass, cab windshield, cab sliding window (right)
  • Cab accessories
  • Suspended seat, operator’s station plating
  • Cab heating
  • Operator’s station instrument panel (right and left), cab console
  • Safety belt
  • Tools, glue kit for cab, paint
  • Transfer decals: cab EEC / cab (US) NAFTA / canopy EEC / canopy (US) NAFTA
• Group 9 – Miscellaneous Equipment / Hydraulics (911-975)
  • Hydraulic tank, attachments supply and return circuit
  • Hydraulic circuit oil cooler, oil cooler, hydraulic oil filter, breather
  • Control valve: 8 spools, Std or Iso equipment control selector switch (US)
  • Slewing-offset selector switch, balancing valve (slewing)
  • Control levers: travelling / accessories, control lever: dozer blade
  • Hydraulic pump
  • Accumulator / electrovalve, accumulator
  • Hydraulic circuit (control’s attachment), control lever: dipper arm / slewing (left), boom / bucket (right)
  • Hydraulic circuit (travelling), (dozer blade), (boom slewing / offset), (platform)
  • Hydraulic circuit (boom / dipper arm / bucket)
  • Hydraulic circuit (accessories – 35 l/min), kit coupler (accessories)
  • Hydraulic circuit (double-acting), (attachment) (grab jaw)
  • Tool holder / mechanical control
  • Bucket, buckets for Quickfit, grading bucket, grading bucket for Quickfit
  • Bulk bag, dozer blade, dozer blade cylinder
  • Cylinder rod protection, pivot pin, boom offset cylinder, lubrication
  • Boom, boom cylinder, dipper arm, telescopic arm, dipper arm cylinder
  • Bucket cylinder, telescopic arm cylinder
• Group 10 – Replaced Parts / Number Index

What This Parts Catalog Gives You

This Volvo EC15B Type 272 XR parts catalog is the reference document you reach for when you need to identify, order or replace a component on this compact excavator. Every group is broken down into exploded-view illustrations with numbered position references, and each number points to a part number, quantity and description in four languages. The engine section alone covers the L3E2-64ESA and L3E-W264ESA power units down to gaskets, pistons, bearings and injection components. The electrical group maps out the battery, alternator, starter, lighting, instrument panels and wiring harnesses. The hydraulic section covers the pump, control valve, cylinders, swivel joint and all the hoses and fittings that connect them. The undercarriage group handles the lower frame, rubber tracks, track tensioning, sprockets and lower rollers. The body group covers the cab or canopy, doors, glass, seat and heating. And the attachments group covers buckets, dozer blade and quickfit options. Whether you are rebuilding a cylinder, tracing a hydraulic hose, replacing a damaged panel or simply ordering a wear part, the illustration and part number combination lets you find the right component without guesswork.

Why This Volvo EC15B Parts Catalog Matters

Parts catalogs are not repair manuals – they do not tell you how to remove a cylinder or torque a bolt. What they do is let you see how an assembly is put together, identify every individual component by its Volvo part number, and order exactly what you need. The exploded views show the relationship between parts, the quantity columns tell you how many are required per machine, and the multilingual descriptions remove language barriers at the parts counter. The catalog also includes a replaced-parts section and a full numerical index so you can cross-reference superseded numbers and locate any part number in the catalog instantly. For anyone maintaining or restoring an EC15B Type 272 XR, this is the document that turns a vague description like “the small hydraulic fitting on the swivel joint” into a precise part number you can actually order.

Get Instant Access

IMAGES PREVIEW

This Volvo EC15B Type 272 XR parts catalog is delivered as an instant PDF download – no shipping, no waiting. You can open it on any device, search through the groups, print the pages you need for the workshop, and keep it on hand whenever you are ordering parts or planning a repair. Whether you are a technician, a workshop manager or an owner-operator, having the correct part numbers and exploded views at your fingertips saves time and prevents costly ordering mistakes.
