Volvo L150H Wheel Loader Parts Catalog PDF – 20039662-E Complete Illustrated Parts Manual

Description

Volvo L150H Wheel Loader Parts Catalog — Complete Illustrated PDF Reference

This Volvo L150H Wheel Loader Parts Catalog is the full illustrated parts reference for the L150H wheel loader, published under catalogue id 20693 with issue number 20039662-E. Spanning approximately 1,652 pages, it delivers exploded-view illustrations, part numbers, quantities, and assembly relationships across the entire machine — from the D13 engine through the cab, hydraulics, electrical system, transmission, axles, brakes, and attachment bracket. Every part presented in the catalogue has been function- and endurance-tested to Volvo Construction Equipment’s quality and safety requirements, and every illustration page pairs directly with its parts list so you can locate a component, confirm its position number, and order the exact part in a single pass.

File Details

• Manual type: Illustrated Parts Catalog
• Brand: Volvo Construction Equipment
• Model: L150H Wheel Loader
• Product number: 33043
• Serial number coverage: 4005 -, 9002 -, 14001 –
• Catalogue id: 20693
• Issue: 20039662-E
• Language: Multilingual — English, French, German, Spanish, Swedish
• Page count: Approximately 1,652 pages
• File format: PDF

Chapters Covered

• Group 1 — Preface and Instructions: group index, product signs, catalogue guide, abbreviation tables, market-adapted equipment list.
• 210 Engine: cylinder head with fitting parts, cylinder block, cylinder liner and piston, valve mechanism, timing gear, crankshaft and related parts, oil sump, engine mounting, lubricating oil system, oil filter, oil cooler, fuel filter, fuel tank, fuel lines, injector, inlet and exhaust manifold, exhaust system and silencer, AdBlue/DEF system, turbocharger, air filter, intercooler, radiator, cooling system, belt transmission, engine heater, hand throttle control, engine ECU, sensors, engine cable harness, and EGR.
• 3 Electrical System: battery box, alternator, starter motor, pre-heater, ignition starter switch, lock kit, front / rear / cab lighting, work lights, horn, back-up warning unit, rotating beacon, windshield wiper, battery main switch, electronic unit, cable harness, electrical distribution box, instrument panel, rocker switch panel, electrical sensors, forward and rear-view camera, monitor, radio installation, and telematics.
• 4 Power Transmission: torque converter, hydraulic transmission, converter housing, gears and shafts, oil filter, oil distributor, hydraulic clutches (forward / 1st, reverse / 2nd, 3rd / 4th), lubricating oil valve, range selector valve, transfer case gears and housing, proportional valve, gear box housing, propeller shafts, planet axles, planetary axle front and rear, and differential lock.
• 5 Brakes: multi-disc brake front and rear, brake lines and pipes, axle oil cooler, dual brake pedals, footbrake valve, brake valve, accumulators, and parking brake.
• 6 Steering System: steering wheel, steering column, steering cylinder, pressure and return lines, steering system, shift valve, secondary steering system, pressure monitor, angle sensor, and CDC steering.
• 7 Frame and Wheels: frame, protecting plates, belly guards, radiator grille protection, rear hitch and counterweight, towing hitch, frame joint vertical bearing, and wheels.
• 8 Cab and Body: cab body roof and floor panel, cab mounting block, hydraulic cab tilt, engine hood, front and rear fenders, widener kits, mud guards, foot steps, side door, door locks, superstructure, rear-view mirrors, glass panes, sliding window, cab accessories, operator seat with fitting parts, seat belt, armrests, hose protection, windshield guard, window guards, hub protection, air filter, air ducts, air conditioning, compressor, condenser, receiver drier, auxiliary heater, front section, interior equipment, fire suppression system, tools, tool box, sign plates, and decals.
• 9 Hydraulics and Miscellaneous: hydraulic oil tank, suction line, feed and return lines, control valve, valve body, relief valve, hydraulic pump, servo hydraulic, boom suspension, 3rd / 4th hydraulic function, attachment bracket hydraulics, bucket tooth protection, towing hitch, attachment bracket, lifting frame work, lift and tilt cylinders, angle sensors, fire suppression system, central lubrication pump and distribution blocks, and cleaner kit.

This 70-plus-section structure means the L150H parts catalog covers far more than a single assembly. It is a complete machine-wide parts reference: engine internals, fuel and air systems, cooling, electrical, driveline, axles, brakes, steering, frame, cab, and the full hydraulic circuit including the loader unit. A technician or parts manager can trace a single component from its system group down to the illustration, position number, and part number.

How the Catalogue Is Organised

Each system is broken into groups and sections. The text pages carry position numbers, part numbers, quantities, descriptions in five languages, and a notes column with replacement, supersession, and status information. Every section references the illustration page it belongs to, so the workflow is straightforward: open the illustration, note the position number of the part, turn to the matching text page, and read the part number, quantity, and any replacement notes. Parts marked with a K are included in a kit, SS flags superseded items, SE points to an alternative version, and NS indicates a part that is not kept in stock.

Equipment Variants Listed

Beyond the core machine, the catalogue documents dozens of product and equipment variants with their kit numbers — tool kits, rear light protection, radiator grill guards, seat belt options, arm rests, noise reduction, automatic greasing systems, work lights in halogen and LED, engine installations, driver’s seats, radio kits, radiator configurations, towing hitches, exhaust systems for different emission stages, cab suspension variants, wheel housings, footstep types, road-light options, counterweights, wheels, operator seats, hydraulic functions, brake systems, and more. This makes the catalogue useful for both standard L150H machines and those fitted with factory options.

Engine Coverage

The engine sections cover the engines listed for this machine under product numbers 15185564 (replacement version 17272079), 15185565 (17272080), 15185566 (17433661), and 15185567 (17429062). Cylinder head, block, liner, piston, valve mechanism, timing gear, crankshaft, oil sump, mounting, lubrication, filter, cooler, fuel system, injector, manifolds, exhaust, turbocharger, air filter, intercooler, radiator, cooling, belt transmission, and EGR are all broken down into their individual parts.

Who This L150H Parts Catalog Is For

This is the reference for anyone who needs to identify, order, or verify parts for a Volvo L150H wheel loader. Fleet maintenance teams use it to confirm part numbers before ordering. Independent workshops use it to cross-reference assemblies and understand how components fit together. Parts departments use it to answer customer queries quickly. Owners of machines in the serial ranges covered can use it to confirm that a given part applies to their machine before purchase.

Order the Right Part the First Time

IMAGES PREVIEW

Working from an illustrated parts catalogue like this one saves time, avoids wrong-part orders, and prevents fitting a non-genuine component that could void warranty or compromise safety. The exploded illustrations make the assembly order clear, the position numbers make each part unambiguous, and the multilingual descriptions remove guesswork. Delivered as an instant PDF download — no shipping, no waiting, viewable on any device, and printable for the workshop bench. Order the Volvo L150H Wheel Loader Parts Catalog today and have the full parts reference for your machine at hand.
