Yale GP GTP GLP GDP 15-35 AK RK TK Forklift Spare Parts List PDF Download

Description

Yale GP GTP GLP GDP 15-35 Forklift Spare Parts List

This is the illustrated spare parts list for Yale GP, GTP, GLP and GDP series forklifts in the 15 to 35 capacity range, covering AK, RK and TK chassis configurations. It is the same parts catalog used to identify, order and replace components across the drive unit, brake, hydraulic, electrical, engine and LPG systems, with every part referenced to its illustration and its part number.

File Details

• Manual type: Spare Parts List (illustrated parts catalog)
• Brand: Yale
• Model coverage: GP / GTP / GLP / GDP 15-35 (AK, RK, TK)
• Engine references: 92 (2.7L) Diesel, 98 (3.3L) Diesel
• Vehicle types: Gasoline (GP), Dual Fuel (GTP), LPG (GLP), Diesel (GDP)
• Language: English (with Spanish decal and label variants for selected markets)
• Page count: 236
• File format: PDF

Chapters Covered

• 1.01 Option – Drive Unit
• 1.02 Option – Steering System
• 1.03 Option – Brake System
• 1.04 Option – Frame and Body
• 1.05 Option – Hydraulic System
• 1.06 Option – Electrical System
• 2.01 Option – Engine
• 2.02 Option – FDC Pedal
• 2.03 Option – Air Intake System
• 2.04 Option – Exhaust System
• 2.05 Option – Cooling System
• 2.06 Option – Alternator
• 2.07 Option – LPG System
• 3.00 Option – Tilt Cylinder
• 4.00 Option – Kit
• 5.00 Option – Other

Drive Unit and Steering

The drive unit section covers single, wide and dual drive tire assemblies for AK and RK/TK trucks, including J-LUG, Aichi Unique and ME310 tire options, split-wheel warning labels, rim wheels, studs, hub nuts and over-fender components. The steering section carries the R.H. shift steer linkage, combination lever assembly, turn signal and direction switches, horn contact, spring and steer-angle sensor for both AK and RK/TK configurations.

Brake System

Single inching brake pedal for Asia/Aus and separate inching brake pedal for Lao are listed in full, followed by the master cylinder assembly with piston, valve, snap ring, boot, push rod, bleeder and reservoir. Heavy duty brake coverage for 30 and 35 TK trucks includes the drive axle assembly, brake backing plates, wheel cylinders, auto adjuster kits, parking parts kits, shoe and lining kits, shoe hold-down kits and spring kits.

Frame, Body, Seating and Decals

Cover top, mirror, canvas cabin, raised overhead guard, front glass and windshield wiper assemblies are documented with their brackets, seals, pads and hardware. Fuel inlet covers, Veracitor and Veracitor LA decals, fan warning, mast warning, park brake warning and operator warning labels are listed in English and Spanish. Suspension and non-suspension seat assemblies, E-HYD seats and their inner parts — pads, frames, slides, grips, belts, buckles and recliner knobs — are covered in detail.

Hydraulic System

Control valve and lever assemblies for 2, 3 and 4 spool configurations appear with both non-ISO and ISO versions, with and without interlock. Spool section assemblies for lift, tilt and attachment circuits are broken down into housings, spools, seal plates, O-rings, wipers, caps, springs, poppets, plugs and relief valves. The port relief valve, electrical E-HYD control, mini levers and associated harnesses round out the section.

Electrical System

Lights group coverage includes head lamp assemblies, turn signal lamps, rear combi lamps, LED rear combi lights, rear working lamps, revolving warning lights, back buzzers with volume change switch and back horn. Lamp inner parts — bulbs, lenses, gaskets and screws — are itemized. Load weight gauge, rear handle, speed sensor, speed limiter drive axle center sections and speed limiter components for GP, GTP and GLP are documented with their harnesses, controllers, actuators, cables and brackets.

Engine, Air Intake, Exhaust and Cooling

The engine section covers the hi-power 30TK F2 gas and F2 LPG engine packages plus the drive axle center section. Air intake dual element and pre-cleaner assemblies, tandem air cleaner for GDP, special and cyclone mufflers, catalytic mufflers for gas and DSL, and vertical exhaust systems are all listed with their hoses, clamps, brackets, gaskets and hardware. Anti-clog and large capacity cooling systems for GP/GTP/GLP and GDP include radiators, fan shrouds, screens, cushions, reservoir tanks, pulleys, belts, ducts, pressure caps and cock assemblies.

Alternator, LPG and Tilt Cylinder

Large capacity and enclosed alternators for GP/GTP/GLP and GDP are documented along with the alternator inner parts — fan, housing, gaskets, seals, bearings, rotor, stator, diodes, regulator, brush assembly, condenser and pulley. The LPG system covers tank options (15KG and 20KG, with or without gauge), connecting tank stop valve, quick coupling for Lao, fuel pressure alarm, low emission system, governor inner parts, converter inner parts, fuel lock filter inner parts and exhaust low emission components. Tilt cylinder assemblies for AK, 20-30RK/TK and 35TK are broken down into cylinder tubes, piston rods, cylinder heads, bushes, U-rings, packing headers, snap rings, wiper rings, O-rings, back-up rings, rod heads, pin bushes and seal kits.

Kits and Other

Valve conversion kits (2SP to 3SP and 2SP to 4SP across AK, 20,25RK/TK, 30TK and 35TK), inching brake pedal conversion kits, shift lever conversion kits, dual tread conversion kits and dual fuel conversion kits are listed with their part numbers. Fire extinguisher options (Type 3 and Type 4) and the tool kit contents — screwdriver, spanners, wheel nut wrenches, monkey wrench, plier, grease gun, plug wrench and tool bag — complete the catalog.

Why This Parts List Matters

Ordering the wrong part for a forklift is expensive and slow. This Yale GP GTP GLP GDP 15-35 spare parts list eliminates the guesswork by tying every component to an exploded illustration, a reference number and an exact part number. Whether you are rebuilding a brake assembly on a 30TK, replacing a tilt cylinder seal kit on an AK truck, tracking down a control valve spool section for a 20,25RK/TK, or simply replacing a fan warning decal, the correct number is here. The numerical parts index at the front lets you jump straight from a part number to its page and item, while each section illustration shows how the parts fit together before you order.

This PDF is delivered instantly after payment — no shipping, no waiting. Open it on any device, print the pages you need for the workshop, and keep the complete Yale GP GTP GLP GDP 15-35 parts catalog on hand for every rebuild, repair and routine replacement job.
