Aerostar 600/601/601P/602P/700P Illustrated Parts Catalog – PDF Manual
Original price was: $44.95.$29.95Current price is: $29.95.
Complete illustrated parts catalog for Aerostar 600, 601, 601P, 602P and 700P aircraft. Includes all assemblies, part numbers, and exploded-view diagrams.
Description
Aerostar 600/601/601P/602P/700P Illustrated Parts Catalog – The Definitive Parts Reference
This is the factory-issued Aerostar Illustrated Parts Catalog, publication number Aero600-IPC.010, specifically compiled for the Aerostar 600, 601, 601P, 602P and 700P series aircraft. It is a comprehensive, part-number-indexed reference that covers every major assembly, subassembly, and individual component of these high-performance twin-engine aircraft. Whether you are performing routine maintenance, conducting a major overhaul, restoring a classic Aerostar, or simply need to identify a specific part for ordering, this catalog provides the authoritative breakdown and exploded-view diagrams needed to get the job done correctly.
What This Illustrated Parts Catalog Contains
This document is not a service or maintenance manual; it is a complete, structured parts identification and ordering guide. It is organized into 14 major sections, mirroring the aircraft’s physical systems and airframe structure. Each section contains detailed exploded-view illustrations and corresponding parts lists, allowing you to visually identify a part and find its exact part number. The catalog covers everything from the airframe structure to the smallest placard and hardware item.
File & Document Details:
- Manual Type: Illustrated Parts Catalog (IPC)
- Publication Number: Aero600-IPC.010
- Brand/Manufacturer: Aerostar Aircraft Corporation
- Applicable Models: Aerostar 600, 601, 601P, 602P, 700P
- Language: English
- Page Count: 640+
- File Format: PDF
- Revision Status: Includes revisions up to April 1996
This Aerostar 600/601/601P/602P/700P Parts Catalog is the definitive guide for locating parts on your specific aircraft. It accounts for airframe and serial number variations, ensuring you order the correct part for your aircraft’s configuration. The catalog is laid out in easy-to-follow sections, making it an indispensable resource for owners, maintenance shops, and A&P mechanics.
Chapters Covered in the Aerostar Parts Catalog
- Section I – Airframe Structure Group
- Wing Assembly Structure
- Nacelle Installation
- Aileron Assembly
- Flap Assembly
- Section II – Fuselage Group
- Complete Fuselage Installation (6 sheets)
- Nose Section Installation
- Forward Fuselage Installation
- Center Section Installation
- Aft Fuselage Installation
- Door Assemblies: Lower/Upper Main Cabin, Emergency Exit
- Cabin Door Holder
- Section III – Empennage Group
- Horizontal/Vertical Stabilizer Assembly
- Elevator/Rudder Assembly
IMAGES PREVIEW
- Section IV – Landing Gear Group
- Nose Landing Gear & Door Installations
- Main Landing Gear & Door Installations
- Wheel & Brake Installations (Cleveland/Goodyear)
- Brake System Installation
- Drag Brace & Bungee Assemblies
- Section V – Cabin Equipment Group
- Interior Furnishing
- Curtain and Window Shade
- Carpet Installation
- Instrument Panel & Console Covers
- Overhead Panel
- Standard & Executive Seating
- Pilot, Copilot, Passenger, Bench, Swivel, and Vertically Adjustable Seats
- Section VI – Instruments Group
- Instrument Panel Installation
- Pneumatic System
- Pitot-Static System
- Alternate Static System
- Engine Instrument Lines
- Section VII – Powerplant Group
- Engine Installations (Lycoming IO-540, TIO-540)
- Exhaust Systems
- Induction Systems
- Baffle Installation
- Powerplant Controls
- Three-Blade Propeller Assembly (Hartzell)
- Propeller Synchrophaser Installation
- Engine Icing Protection Modification
- Section VIII – Fuel System Group
- Fuselage Fuel and Vent System
- Wing Fuel and Vent System
- Nayak Fuel System Installation
- Section IX – Control System Group
- Aileron Control
- Flap and Nose Gear Control
- Elevator Control
- Rudder Control
- Flight Control Wheel & Control Column
- Section X – Hydraulic System Group
- Forward, Aft, and Flap Hydraulic Systems
- Auxiliary Hydraulic Installation
- Section XI – Environmental Group
- Heating, Ventilating, and Defrosting System
- Heater Fuel System
- Cabin Ventilation
- Oxygen System
- Pressurization System
- Alcohol/Electric Windshield De-Ice
- Pneumatic Surface De-Ice
- Air Conditioning Installation
- Section XII – Electrical System Group
- Forward, Aft, and Instrument Panel Harness
- Primary and Auxiliary Electrical Power
- Strobe, Landing, and Ice Detection Lights
- Circuit Breaker Panel
- Propeller Electric Deicer
- Electric Windshield Deicer
- Annunciator Panel
- Section XIII – Electronics Group
- ELT Installation
- Antenna System, Speakers, Static Wicks, Avionics Fan
- King KFC-200, KAP 150, KFC 150 Autopilots
- Bendix FCS-810 Autopilot
- Mitchell Century III, IV, and 41 Autopilots
- King & Bendix Radar Installations
- Bonzer & KRA-10A Radar Altimeters
- Section XIV – Miscellaneous Group
- Placard and Exterior Stencil Installation
- Optional Equipment Kits, Repair Kits, and Special Tools
- Numerical Parts Index
This Aerostar Illustrated Parts Catalog is an essential tool for any owner or mechanic. It provides the exact exploded-view diagrams and part numbers required to identify and order replacement components for your aircraft. Using the correct factory-specified parts is critical for maintaining the airworthiness, safety, and performance of your Aerostar. The catalog also includes vital information on serial number applicability, ensuring you get the right part for your specific airframe.
