BOMAG BW 216 D-5 Vibratory Roller Spare Parts Catalogue – 2016-2018

Description

BOMAG BW 216 D-5 Vibratory Roller Spare Parts Catalogue

This is the complete spare parts catalogue for the BOMAG BW 216 D-5 single drum wheel drive vibratory roller, covering serial numbers from 101586261001 through 101586261197. Published by Bomag GmbH under catalogue number 001.05.2016 – 01.07.2018, this 876-page PDF provides the full parts breakdown for every major assembly on the machine. The catalogue is trilingual, with part descriptions in English, German, and French throughout, and is built around exploded-view illustrations that make part identification straightforward.

File Details

• Manual Type: Spare Parts Catalogue (Ersatzteilkatalog / Catalogue de pièces detachees)
• Brand: BOMAG (Fayat Group)
• Model: BW 216 D-5 Single Drum Wheel Drive Vibratory Roller
• Engine: Deutz TCD 4.1 L4 115kW/2100 Tier 3a
• Serial Number Range: 101586261001 > 101586261197
• Catalogue Number: 001.05.2016 – 01.07.2018
• Language: English, German, French
• Page Count: 876
• File Format: PDF

Chapters Covered

• 10 Engine / Fitting Parts: engine parts list, crankcase, oil pan, crankshaft, cylinder head, control pieces, oil and fuel filter, lube oil cooler, lube oil tube, injection pump, injection valve, fuel pipes, suction pipe and exhaust, throttle control, cooling blower, turbocharger, generator and starter, engine mounts, electrical equipment, hydraulic pump, seal kit, water cooling, exhaust treatment
• 12 Engine Installation: engine, pump mounting, gear pump assembled, exhaust system, filter support assembled, radiator, air duct
• 19 Air and Cooling: dry air filter, combination radiator
• 20 Power Transmission / Actuation: axle, control lever, drive axle, gear unit for travel
• 40 Steering System: steering, joint mounting, link assembled
• 50 Frame with Attachment Parts: front frame, rear frame, front frame assembled, access steps, access steps assembled, belt rewinder assembled, locking pin assembled, hood, operator’s seat, fuel tank, oil tank, scraper, scraper assembled, fuel tank assembled, oil tank assembled, operators platform, engine hood
• 60 Drum / Tyres: exciter unit right assembled, exciter unit left assembled, exciter unit assembled, roller drum and drum drive, basic weight assembled, tyres
• 80 Electrical System: instruments, central electric, electrics, electrical box assembled, powerboard assembled, wire harnesses
• 90 Hydraulic: hydraulics, hydraulic tandem pump, hydraulic motor, hydraulic motor travel system, gear pump, hydraulic oil filter, valve block
• 100 Accessories: decals
• 110 Special Equipment: M35 winter package, M5 V-belt protection cover, S5 ROPS-FOPS, K2 heating, E21 radio, S21 ROPSCabin with heater, FS4 outside mirror, S31 ROPSCab with heating-air conditioning, vandalism protection assembled, VM20 ECONOMIZER, Q8 plate scraper, scraper assembled, FS36 comfort package, gas spring assembled, cab, heating unit, heating climatic unit, operator’s seat, sliding window, B48 drum long life, B5 pad foot segment kit, T6 tractor profiled tyres, T29 rock tyres, T43 radial tyres, E2 lighting-StVZO, E60 broad spectrum buzzer, E82 LED working headlights, E83 ECOSTOP, FS27 electronic burglary protection, E66 Bomag Telematic Power, AZ12 tachograph with connector, VM29 printer, VM33 BOMAG Terrameter, VM38 interface measurement, printer assembled, E36 reversing monitoring, headlight, HY2 bio hydraulic oil, SW1 service kit 1000h, SW6 oil service kit

The catalogue is built around exploded-view illustrations with numbered callouts that correspond to detailed parts tables. Each table lists the part number, quantity, description, and designation in three languages. Every major assembly of the BW 216 D-5 is broken down to the individual component level, making it straightforward to identify the exact part needed for any repair or rebuild job. The document also includes wear parts, seals, gaskets, hardware, and complete assembly kits.

How the Catalogue Is Organized

The BW 216 D-5 parts catalogue follows the manufacturer’s standard numbering system. Sections are grouped by system: engine (10 and 12 series), power transmission (20 series), steering (40 series), frame and attachment parts (50 series), drum and tyres (60 series), electrical system (80 series), hydraulics (90 series), accessories (100 series), and special equipment (110 series). Each section begins with an overview illustration showing the general assembly, followed by detailed exploded views and parts lists that break the assembly down into individual components.

Within each section, parts are numbered sequentially and cross-referenced to the illustration. The parts tables show the position number, BOMAG part number, quantity required, description, and designation in English, German, and French. This layout makes it possible to trace any part from the diagram to its order number without ambiguity. The catalogue also notes serial number breakpoints where parts differ across the production run, so you can order the correct variant for your specific machine.

Engine and Powertrain Coverage

The engine section covers the Deutz TCD 4.1 L4 in complete detail. You will find parts breakdowns for the crankcase, oil pan, crankshaft, cylinder head, control pieces, oil and fuel filters, lube oil cooler, lube oil tube, injection pump, injection valve, fuel pipes, suction pipe and exhaust, throttle control, cooling blower, turbocharger, generator and starter, engine mounts, electrical equipment, hydraulic pump, seal kit, and water cooling. The exhaust treatment section covers the aftertreatment components. The engine installation section covers the pump mounting, gear pump, exhaust system, filter support, radiator, and air duct.

The power transmission section covers the axle, control lever, drive axle, and gear unit for travel. The travel gear unit is broken down to the level of individual gears, bearings, seals, and brake components. The drive axle section includes the axle housing, axle shaft, planetary housing, wheel hub, wheel bolts, and wheel nuts. The steering system section covers the steering column, steering wheel, steering valve, joint mounting, and the complete link assembly with spherical plain bearings, seals, and mounting hardware.

Drum, Exciter, and Tyre Coverage

The drum and tyre section covers both exciter units (left and right), the complete exciter unit assembly, the roller drum with drum drive, the basic weight assembly, and all tyre options. The exciter unit breakdown includes the shaft, bearings, seals, flanged housing, and related hardware. The drum drive section covers the hydraulic motor, gear unit, drive disc, transmission support, and mounting hardware. Tyre options include the standard tyres, tractor-profiled tyres, rock tyres, and radial tyres, with complete wheel assemblies and individual tyre, rim, and valve part numbers.

Electrical and Hydraulic Coverage

The electrical system section covers instruments, central electric, electrics, electrical box, powerboard, and wire harnesses. The wiring harnesses are broken down by connector and circuit, with part numbers for individual connectors, cable channels, plugs, and cables. The hydraulic section covers the hydraulic tandem pump, hydraulic motor, hydraulic motor for the travel system, gear pump, hydraulic oil filter, and valve block. The tandem pump is broken down into its two pump sections with individual components including cylinder blocks, valve plates, swash plates, servo pistons, and seal kits.

Special Equipment and Options

The special equipment section is extensive, covering the many optional features available for the BW 216 D-5. This includes the M35 winter package, M5 V-belt protection cover, S5 ROPS-FOPS structure, K2 heating, E21 radio, S21 ROPSCabin with heater, FS4 outside mirror, S31 ROPSCab with heating and air conditioning, vandalism protection, VM20 ECONOMIZER, Q8 plate scraper, FS36 comfort package, gas spring, cab, heating unit, heating climatic unit, operator’s seat, sliding window, B48 long life drum, B5 pad foot segment kit, various tyre options, lighting packages, broad spectrum buzzer, LED working headlights, ECOSTOP, electronic burglary protection, Bomag Telematic Power, tachograph, printer, BOMAG Terrameter, interface measurement, reversing monitoring, headlight, bio hydraulic oil, and service kits.
