Ford 7610 Tractor Parts Catalogue 1981-1991 – Series 10 Illustrated Parts Manual PDF (Portuguese & English)

Description

Ford 7610 Tractor Parts Catalogue – Series 10 (1/81–10/91)

This is the full illustrated parts catalogue for the Ford 7610 4-cylinder tractor, Series 10, covering production from 1/81 through 10/91. Every figure shows an exploded assembly drawing with a numbered reference key, and each number is tied to a part number, quantity and description in the accompanying table. Text is presented side by side in Portuguese and English, so both language groups can order components directly from the same document.

File Details

• Manual type: Illustrated Parts Catalogue
• Brand / model: Ford 7610 (4-cylinder, Series 10)
• Coverage years: 1/81 – 10/91
• Languages: Portuguese and English (bilingual)
• File format: PDF
• Page count: Approx. 951 pages

Chapters Covered

• 01 – Front Wheel Assembly / Rodas Dianteiras
• 02 – Brakes & Brake Controls
• 03 – Front Axle, Steering & Related Parts
• 04 – Rear Axle, Differential & Related Parts
• 05 – Hydraulic Lift & Remote Controls
• 06 – Engine – Cylinder Block, Head, Crankshaft, Camshaft, Fuel, Cooling
• 07 – Transmission, PTO, Clutch, Gearshift
• 08 – Radiators, Water Pump, Oil Cooler
• 09 – Fuel System & Injection
• 10 – Hydraulic Pump Assembly
• 11 – Electrical System, Lamps, Battery, Alternator, Starter
• 12 – Instrument Clusters & Monitors
• 13 – Seats
• 14 – Fenders, Platforms & Tool Boxes
• 15 – Cab, Roof, Glass, Heater & A/C
• 16 – Identification & Safety Decals
• 17 – Accessories, Tools, Mirrors & Paints

Wheels, Axles & Steering

Front and rear wheel assemblies, rim and disc options (including W10 x 24, W12 x 28, W12 x 24, DW14-26, DW16 x 26 and other rim sizes listed), hubs, bearings, seals, spindles, king pins, planet carriers and mud fenders. Power steering sections cover the steering gear, steering motor, pump, reservoir, cooler and cylinder assemblies, with exploded views of the Ross and TRW motors and all associated valves and seals.

Brakes & Handbrake

Outer and inner brake housings, disc assemblies, actuators, pedals, linkage rods and clevises for cab and non-cab variants. Transmission handbrake assemblies are broken down for L/Cab and W/Cab, and twin-cable handbrake systems are illustrated with their cables, levers and brackets. Hydraulic trailer brake plumbing and pedals are also included.

Transmission & PTO

The 8-speed non-synchronised and synchronised transmissions are both documented, including gear clusters, mainshafts, countershafts, synchroniser rings, shift rails, forks and the complete gearshift cover assemblies. Dual Power units are exploded, and the single-speed and 2-speed PTO assemblies, PTO guards, pulleys and clutch linkages are covered with all bearings, plates and seals.

Engine

Cylinder block, head and related castings; crankshaft, flywheel, balancer and pulley assemblies; camshaft, tappets, pushrods, rocker arms and valves. The fuel system chapter covers the inline injection pump, the DPS rotary injection pump, injector assemblies and the full fuel line and filter routing. Cooling system coverage includes radiators, water pumps, thermostats, hoses, oil coolers and the coolant filter and reservoir kits.

Hydraulics & Rear End

Hydraulic lift cover, lift cylinder, lift shaft, rocker arms, lower links and check chains. Deluxe remote control valves, manifolds, couplers, unload valves and oil filter assemblies are exploded for 1 through 4 remote configurations. Rear axle housing, differential, differential lock controls, centre housing and PTO centre housing assemblies round out this section.

Cab, Body & Electrical

Cab body, doors, roofs, front/side/rear glass, weatherstrips and latches for both the 81/9-85 and 10-85/ cab series. Interior trim, floor mats, instrument panels, steering columns and seating options (Super Comfort, Custom Deluxe, Bostrom and Grammer) are all itemised. Electrical sections cover main harnesses, fuse boxes, switches, relays, alternators (32, 45, 46, 51, 55, 70 and 80 amp), starters, batteries, lamps, flasher units and trailer sockets.

Decals, Accessories & Tooling

Identification decals, stripe kits, safety and instruction decals, shift pattern decals and paint part numbers. Accessory chapters cover front end wafer weights, rear wheel weights (30″, 34″, 36″ and 38″), tow hooks, swinging drawbars, automatic pick-up hitches, three-point stabiliser kits, mirrors, radio installations, engine coolant heaters and tool kits.

Why This Parts Catalogue Matters

Ordering the wrong part wastes time and money. This catalogue exists precisely so the correct part number can be identified before the order is placed. Every numbered balloon on an exploded view has a matching table row with the Ford part number, quantity and description — so a mechanic, parts counter or restorer can trace a component from the drawing straight to the number needed. When a single assembly like the dual power unit or the steering motor contains dozens of small seals, bearings and springs, that correspondence is what prevents costly mis-orders and keeps the machine working as designed.

IMAGES PREVIEW

Instant PDF Delivery – Print or View on Any Device

Your download is available immediately after checkout. The entire Ford 7610 parts catalogue arrives as a single PDF that opens on a workshop PC, laptop, tablet or phone, and any page can be printed for use on the bench. No shipping, no waiting, no postage — just the complete illustrated parts reference for the 7610 Series 10, ready when you need to put a part number against a drawing.
