Hangcha CPC-Q-D 80-100 H Series Forklift Parts Catalogue PDF Download

Description

Hangcha CPC-Q-D 80-100 H Series Forklift Parts Catalogue

This is the complete illustrated parts catalogue for the Hangcha CPC-Q-D 80-100 H Series forklift range. It covers every major assembly from the counterbalance and drive axle through to the mast, fork carriage, hydraulic cylinders and full electrical system. Each section presents an exploded diagram paired with a detailed parts table listing item numbers, part numbers, descriptions and quantities, so you can identify exactly what you need for any 8-ton or 10-ton model in this series.

File Details

• Manual type: Illustrated Parts Catalogue
• Brand: Hangcha
• Series: CPC-Q-D 80-100 H
• Language: English / Chinese (bilingual)
• File format: PDF
• Page count: 163 pages
• Format: Exploded diagrams with parts tables

Chapters Covered

• Counter Balance (80DH-010000 / 100DH-010000)
• Driving System (80DH-200000 / 100DHB-200000)
• Drive Axle Assembly (80DH-210000)
• Drive System / Power System (80DH-300000, 100DH-300000, 80DHA-300000, 100DHA-300000, 80DHW14-300000, 100DHW14-300000)
• Air Inlet System (80DH-310000, 100DHA-310000, 100DHB-310000)
• Exhaust System (80DH-320000, 100DHB-320000, 80DHA-320000, 100DHA-320000)
• Cooling System (80DH-330000, 100DHB-330000, 80DHW14-330000, 100DHA-330000)
• Fuel System (80DH-340000, 100DHA-340000)
• Steering Axle (80DH-410000)
• Steering Cylinder (80DH-411000)
• Steering Device (80DH-420000)
• Truck Body System I, II, III (80DH-500000 / 100DH-500000)
• Instrument Panel (80DH-520000)
• Overhead Guard (80DH-550000)
• Brake and Inching Control I & II (80DH-610000)
• Left and Right Brake Oil Pipes (80DH-610200 / 80DH-610100)
• Throttle Control (80DH-620000, 100DHB-620000, 100DHA-620000)
• Handle Control / Handbrake (80DH-630000)
• Change Over Control (80DH-640000)
• Multi-Way Valve Control (80DH-710000)
• Booster Piping Assembly (80DH-720000)
• Steering Oil Pipe I & II (80DH-730000 / 100DH-730000)
• Torque Converter Oil Cooling Pipe Assembly (80DH-740000)
• Main Working Oil Pipe (80DH-750000)
• Oil Pump Assembly (80DH-751000)
• Tilting Cylinder Tube Assembly (80DH-752000)
• Electrical System (80DH-800000, 80DHW14-800000, 100DHA-800000)
• Lifting Part (8M3-000000 / 10M3-000000)
• Outside Mast (8M3-100000 / 10M3-100000)
• Inside Mast (8M3-200000 / 10M3-200000)
• Fork Shelf (8M3-300000 / 10M3-300000)
• Adjust Cylinder (8M3-304000)
• Tilting Cylinder (8M3-400000)
• Left and Right Lifting Cylinders (8M3-500000 / 8M3-600000, 10M3-500000 / 10M3-600000)
• Main Oil Pipe System (8M3-700000 / 10M3-700000)
• Adjust Oil Pipe System I & II (8M3-800000 / 10M3-800000)

Whether you are rebuilding a steering axle, replacing a hydraulic cylinder seal kit, tracking down a faulty sensor in the electrical system, or simply ordering a new set of forks, this catalogue gives you the exact part numbers and quantities for every component. The exploded views make it straightforward to see how each assembly fits together, which is invaluable when a machine has been apart for weeks or when you are working on a model you have not seen before.

Why This Parts Catalogue Matters

Ordering the wrong part costs time and money. This Hangcha CPC-Q-D 80-100 H Series parts catalogue removes the guesswork by giving you the manufacturer’s own part numbers alongside clear diagrams of every assembly. You can confirm at a glance whether a component is shared between the 8-ton and 10-ton models or unique to a specific variant such as the 80DHW14 or 100DHB. That level of precision is exactly what you need when a forklift is down and every hour of downtime matters.

Models Covered

• 80DH — 8-ton forklift
• 100DH — 10-ton forklift
• 80DHA / 100DHA — 8-ton and 10-ton variants
• 80DHB / 100DHB — 8-ton and 10-ton variants
• 80DHW14 / 100DHW14 — 8-ton and 10-ton variants
• 80DHG14 — 8-ton variant

Engines Referenced

• CY6102BG-2 diesel engine
• YC6105G (J7110) diesel engine
• YC6105G (J7109) diesel engine
• LRC6105G62 diesel engine
• 6BG1QP diesel engine

What You Can Do With This Catalogue

This is a working document for anyone who maintains, repairs or restores a Hangcha 8-ton or 10-ton forklift from the CPC-Q-D 80-100 H Series. Use it to:

• Identify and order replacement parts with confidence using manufacturer part numbers
• Understand how major assemblies fit together before disassembly
• Check whether a part is shared across 80DH, 100DH, 80DHA, 100DHA, 80DHB, 100DHB, 80DHW14 or 100DHW14 models
• Rebuild steering, braking, hydraulic and electrical systems with correct component references
• Plan maintenance and overhaul work with a clear picture of every sub-assembly
• Verify quantities required for a complete repair

The manual covers the full machine: engine mounting and ancillaries, transmission and drive axle, cooling and fuel systems, steering axle and cylinders, body panels and overhead guard, brake and inching controls, throttle and handbrake linkages, multi-way valve and hydraulic piping, the complete electrical system with wiring diagrams, and the entire mast and carriage assembly including lifting cylinders, tilting cylinders, fork shelves and adjust cylinders. Whatever system you are working on, the relevant diagram and parts list is here.
