Linde N20 N24 N20L N20LI Forklift Spare Parts List 132 804 90 01 – PDF Parts Catalog

Description

Linde N20 / N24 / N20L / N20LI Forklift Spare Parts List – 132 804 90 01

The Linde N20, N24, N20L and N20LI forklift spare parts list is the complete factory parts catalogue issued under document number 132 804 90 01 in April 2014. It is organised into ten numbered registers covering the traction motor, drive and transmission, chassis, steering, braking and wheels, electric equipment, hydraulics, lift masts, special equipment and miscellaneous hardware. Every entry carries the original Linde part number, an item designation, the required quantity and, where relevant, the replacement or interchangeable part that supersedes it. This is the same parts list referenced by Linde service technicians and parts counters when one of these trucks comes in for repair or overhaul.

File Details

• Manual type: Spare Parts List (parts catalogue)
• Brand: Linde
• Models covered: N20, N24, N20L, N20LI (with interchange notes for N20HP / N24HP)
• Language: English
• Page count: 335
• File format: PDF
• Document number: 132 804 90 01
• Issue date: 04.14 (April 2014)

Chapters Covered

• Register 01 – Power Unit: Engine / Motor
• Register 02 – Drive: Transmission
• Register 03 – Chassis Unit
• Register 04 – Steering, Braking and Wheels
• Register 06 – Electric Equipment
• Register 07 – Hydraulic Unit
• Register 08 – Lift Mast
• Register 09 – Special Equipment
• Register 10 – Miscellaneous

Register 01 – Power Unit: Engine / Motor

Register 01 lists the traction motor assemblies that drive the N20 and N24 trucks. Each motor is broken down into its individual components – armature, bearing set, locking rings, terminal board, seal, bushing housing, sensor, contact and castellated nut – with the original Linde part number alongside each item. Two drive motor part numbers are shown (W4X132T02011 and W4X132T02012), so you can match the exact build fitted to your machine rather than guessing by year.

Register 02 – Drive: Transmission

The transmission register covers the complete drive unit, the reduction gearbox and the wheel drive assembly. Separate sub-lists break out the housing, cover, hub, gear assembly, pinion gear, wheel bolts, spacer bushes, tapered roller bearings, shims and sealing rings. Several bearing part numbers are shown alongside alternative shim thicknesses (0.1, 0.15, 0.25, 0.3 and 0.5 mm) so you can set the correct preload during a rebuild. Socket-head screws, lock washers and seal rings are all itemised with their DIN standards.

Register 03 – Chassis Unit

Chassis coverage includes side-loading and up-side battery equipment for 3PZS and 4PZS packs, the frame equipment, overhead guard assemblies, the rear control module for both N20/N24 and N20L/N20LI variants, the driver platform and the cold-store floor plates. Beam supports, retainer plates, clamping pieces, harness sockets and the gas spring for the seat support are all listed with their quantities. This is the register to consult when you need the correct overhead guard for a specific mast configuration or the correct battery retainer for a 2PZS, 3PZS or 4PZS pack.

Register 04 – Steering, Braking and Wheels

Register 04 covers the steering gear, tiller assembly, retainer plate, electrohydraulic brake, wheels, load castors and bogies. The bogie listings are extensive: standard, N20L, initial-lift N20LI, lubricated-fitting and lubricated-fitting LI variants are all broken out separately, with the Australian-fork load castor assembly listed on its own. Interchange notes for the N20HP / N24HP and four-point castor configurations are included. Brake components include the brake disc, hub, flange, set of linings, pipe adaptor, gasket and reamer.

Register 06 – Electric Equipment

The electric equipment register lists the traction control assemblies for N20/N24 and N20L/N20LI, the main harnesses for four-point and five-point configurations, the N20L and N20LI harnesses, plugs, contactors, fuses, potentiometers, the fan, the steering control assembly (LES-40/10, LES-40/11, LES-40/12), the impulse control system (LAC-03/10, LAC-03/11, LAC-03/12, LAC-03/31 and LAC-03/61 CC01-CC06) and the output modules. Cable shoes, contact pins, seals, gaskets, wedges, bushings, plug housings and the mounting housing are itemised in sub-lists with their part numbers and their positions in the connector.

Register 07 – Hydraulic Unit

Register 07 is the hydraulic register. It covers the complete hydraulic unit for every variant (N20/N24, N20HP/N24HP, N20L, N20LI and the wheel-castor variants with battery side exit or up-side), the control valve assemblies, the pump aggregate assemblies for N20, N24, N20L and N20LI, and the individual pump motor units. Lift cylinders, flexible formed hoses, pipe unions, oil tanks, non-return valves, pressure relief valves, solenoid valves, screen filters, suction filters, O-rings, back-up rings and snap rings are all broken out with their part numbers. Two document revisions are covered on the N20 pump motor unit (W4X132U01148 and W4X132C01870), with date-stamped valve and non-return-valve changes noted.

Register 08 – Lift Mast

The lift mast register covers the hoist assemblies for battery side exit and battery up side on N20/N24 (both the earlier and the later replacement variants), the N20L and N20LI hoist assemblies, mast types S, E and D for N20L/LI, the fork carriages for E, S and D masts, the load backrest, right and left cylinders for type D, side cylinders for type S, lift cylinders Ø35 and middle cylinders for types D and E. Fork carriages are listed by fork width and battery pack size (520, 540, 560 and 680 mm; 3PZS and 4PZS) with high-capacity options. Push rods, connecting rods, lift shafts, lift swings, chain anchors, leaf chains and line-break safety valves are all itemised.

Register 09 – Special Equipment

Special equipment covers the battery holders for 2PZS, 3PZS, 4PZS, 5PZS and 6PZS packs, the mobile battery trolley, the Pack N°2 3PZS-4PZS assembly, the safety device, the standard pack, the loadguard assembly, the accessories bracket, the support and the switch assembly. Battery holder rollers, rods, spring washers, lock washers, beam supports, threaded rods and hexagon nuts are all listed with quantities so you can rebuild a complete holder or just replace a worn roller.

Register 10 – Miscellaneous

The miscellaneous register contains manufacturer’s plates, nameplates, labels, capacity rating plates, warning labels, restriction symbols and lifting sling plates. Linde and Fenwick branded plates are both listed, along with the model labels for N20, N24 and P30, the cold-store label and the emergency-stop and ignition labels shown elsewhere in the chassis register.

How the Linde Part Number Lookup Works

The middle of the catalogue is a master part-number index. It lists every part number together with the page reference and register number where that part appears. If you already know the Linde part number, you can jump straight to the correct exploded view instead of searching through every register. If you only have the machine model and the component, the register structure above gets you to the right diagram first. Either way, you spend your time ordering the correct part, not hunting for the page.

Replacement Notes and Interchangeability

Throughout the catalogue, parts that have been superseded are shown with a replacement arrow. For example, drive motor W4X132T02011 is replaced by W4X132T02012, and several hoist and hydraulic assemblies are updated to later W4X132 series numbers. The N20HP / N24HP parts that interchange with the N20/N24 series are flagged, as are the four-point castor configuration parts. This makes it possible to order the current equivalent of a part that may have been in stock for years, rather than chasing an obsolete number that no longer exists in Linde’s system.

Who This Linde Parts List Is For

This Linde N20 N24 N20L N20LI spare parts list is written for the people who actually keep these trucks running: workshop technicians rebuilding a traction motor or drive unit, parts managers matching a customer enquiry, fleet engineers planning a scheduled overhaul and independent repair shops that want the correct Linde part number rather than a generic substitute. Because the catalogue covers the full machine – power unit, transmission, chassis, brakes, steering, electrics, hydraulics, mast and special equipment – it works as a single reference for the whole truck rather than a fragment covering one assembly.

Why the Correct Linde Part Number Matters

Forklifts are safety-critical machines, and a wrong bearing, seal, brake lining or hydraulic valve can fail in service with consequences far beyond the cost of the part. The Linde N20 N24 N20L N20LI parts list removes the guesswork by giving you the exact part number, quantity and, where relevant, the replacement number that Linde currently supplies. It also shows which parts are interchangeable between variants, so you can use stock that already exists in your workshop instead of ordering a new item unnecessarily.
