Description
M1266A1 MRAP Operator Manual TM 9-2355-444-10 – 2015 Armored Ambulance PDF
is the complete U.S. Army operator’s technical manual for the Mine Resistant Ambush Protected M1266A1 (NSN 2355-01-620-0199) Long Wheel Base ambulance. Published 30 January 2015 under Headquarters, Department of the Army, this 836-page PDF walks the driver, commander, gunner, medic, and crew through every control, indicator, driving procedure, emergency response, and crew-level maintenance task the M1266A1 requires in forward areas.
File Details
- Manual type: Operator’s Manual / Crew Maintenance Technical Manual
- Document number: TM 9-2355-444-10
- Equipment: Mine Resistant Ambush Protected (MRAP) M1266A1
- NSN: 2355-01-620-0199
- End item code: EIC XXX
- Language: English
- File format: PDF
- Date of issue: 30 January 2015
- Page count: 836 pages (66 front and rear pages across 110 work packages)
- Chapters: 5
Chapters Covered
- Chapter 1 — General Information, Equipment Description and Theory of Operation
- Crew Maintenance General Information, Corrosion Prevention and Control, storage and shipping preparation
- Equipment Description and Data (vehicle weight, dimensions, performance, capacities)
- Theory of Operation — ambulance, drivetrain, suspension and axles, braking, electrical, fuel fired heater, fuel system, pneumatic system, HVAC, AFES, FSS, hydraulic rear door/ramp, CTIS, ESC, rear differential lock, OGPK
- Chapter 2 — Operator Instructions
- Description and Use of Operator Controls and Indicators (IP cluster, LSS/HVAC panel, AFES/FSS controls, ITDS, MVLS, transmission gear selector, CTIS DDM, gauges, switches)
- Operation Under Usual Conditions — side doors, seat adjustment, seat belts, engine start, normal driving, engine shutdown, brake and ABS operation, engine brake, transmission, four-wheel drive, rear door/ramp, fuel fired heater, 110V outlets and inverter, 12V auxiliary outlets, sliding hatch, IGRS, BEATS, gunner platform, OGPK, LSS/HVAC, spotlights, cruise control, hood, fueling, CTIS, RACC, litter lifting and securing, litter trolley and rails, securing medical equipment
- Operation Under Unusual Conditions — RPG-net side doors, extreme heat/dust, mud/sand/snow, extreme cold starting, operating in extreme cold, tire chains, throttle idle control, night vision, fording, steep grades (ascending and descending), driver towing, winch, manual rear door/ramp
