Piper Cherokee PA-28-140/150/160/180/235 & PA-28R-180/200 Service Manual – 2008 Revision
$29.95 Original price was: $29.95.$17.95Current price is: $17.95.
Complete factory service manual for Piper Cherokee PA-28 and PA-28R series aircraft. Covers all major airframe, engine, landing gear, electrical, and systems with detailed procedures and specifications.
SKU: PIP-753586-HEY
Category: Aircraft Service Manuals
Tags: Lycoming O-320 O-360 Engine Manual, PA-28 Maintenance PDF, PA-28R Arrow Repair Guide, Piper Cherokee Service Manual
Vendor: Mower Service Manuals
⚡
Instant PDF Download
Available immediately
💾
Save to Your Device
Download & keep forever
🛡️
Antivirus Scanned
100% virus-free
🌍
Trusted Worldwide
175,000+ customers
Description
Piper Cherokee PA-28 & PA-28R Factory Service Manual – Complete PDF Download
This is the comprehensive, factory-authorized service manual for the entire Piper Cherokee PA-28 family, including the fixed-gear PA-28-140, -150, -160, -180, and -235 models, as well as the retractable-gear PA-28R-180 and -200 Arrow models. Spanning all model years from the early 1960s through 1977, this 1,024-page manual is the definitive guide for maintenance, repair, overhaul, and troubleshooting of these iconic single-engine aircraft. This is the January 31, 2008 revision (PR080131), which supersedes all earlier versions.
File Details
- Manual Type: Factory Service Manual / Instructions for Continued Airworthiness
- Document Number: 753-586
- Revision Date: January 31, 2008 (Partial Revision)
- Language: English
- Page Count: 1,024 pages (approx.)
- Format: PDF – Instant Download
- Publisher: Piper Aircraft Corporation
Chapters Covered
The manual is organized into 14 comprehensive sections, mirroring the aircraft’s systems and providing structured, task-oriented procedures:
IMAGES PREVIEW
- Introduction: Instructions for Continued Airworthiness, effectivity, serial number explanation, and publication details.
- Section I – Airworthiness Limitations: FAA-approved limitations, life-limited part marking and disposition.
- Section II – Handling & Servicing: Dimensions, station reference lines, jacking, weighing, leveling, mooring, towing, cleaning, and comprehensive servicing procedures for all systems (oleo struts, brakes, tires, power plant, fuel, and electrical). Includes lubrication charts and a list of consumable materials.
- Section III – Inspection: Complete inspection program including annual/100-hour inspection checklists, progressive inspection tables, and special inspections for critical components like wing spars, fuel tanks, and control cables.
- Section IV – Structures: Removal and installation of wings, flaps, ailerons, empennage (stabilator, rudder, vertical fin), doors, and windows. Also covers structural repairs (metal, fiberglass, thermoplastic), safety walk repair, and control surface balancing.
- Section V – Surface Controls: Rigging, adjustment, and maintenance of aileron, stabilator, rudder, and flap control systems. Includes control column and rudder pedal assembly procedures.
- Section VI – Hydraulic System (PA-28R): Complete information on the landing gear hydraulic system, including the pump/reservoir, gear back-up extender actuator, and actuating cylinders. Covers removal, disassembly, overhaul, and adjustment.
- Section VII – Landing Gear & Brakes (PA-28): Detailed coverage of the fixed landing gear system, including disassembly, assembly, and servicing of nose and main gear oleo struts, wheels, and brakes. Includes brake bleeding and troubleshooting.
- Section VIIA – Landing Gear & Brakes (PA-28R): Comprehensive procedures for the retractable landing gear system, including gear removal, adjustment, alignment, limit switch adjustment, and door rigging.
- Section VIII & VIIIA – Powerplant: Extensive engine maintenance, removal, installation, and adjustment procedures for Lycoming O-320, O-360, and O-540 engines. Covers propeller (fixed-pitch and constant-speed), governor, carburetor, fuel injection, ignition system (magnetos, harness, spark plugs), and lubrication.
- Section IX – Fuel System: Detailed instructions on fuel tanks (main and tip), quantity transmitters, selector valves, filters, and electric fuel pumps. Includes troubleshooting and fuel system cleaning procedures.
- Section X – Instruments: Maintenance, testing, and adjustment of all flight and engine instruments, including vacuum system, suction gauge, gyros, altimeter, airspeed, compass, and engine gauges (EGT, CHT, fuel flow).
- Section XI – Electrical System: In-depth information on the 14-volt DC electrical system, covering generator, alternator, voltage regulator, starter, battery, and wiring schematics. Includes bench testing and component overhaul.
- Section XII – Electronics: Instructions for Emergency Locator Transmitter (ELT) and general autoflight system information.
- Section XIII – Heating & Ventilation: Details on the cabin heater, defroster, and fresh air systems.
- Section XIV – Accessories & Utilities: Comprehensive coverage of the optional air conditioning system, including servicing, charging, leak testing, and component removal/installation. Also covers the restraint system, overhead vent blower, and fire extinguisher.
Complete PDF Bookmark Tree
Complete Bookmarks
The complete bookmarks in the “Piper Cherokee PA-28-140/150/160/180/235 & PA-28R-180/200 Service Manual – 2008 Revision” are as follows:
+753-586 – CHEROKEE SERVICE MANUAL – PA-28-140/150/160/180/235 AND PA-28R-180/200p. 1
AEROFICHE EXPLANATION AND REVISION STATUSp. 2
TABLE OF CONTENTSp. 3
+INTRODUCTIONp. 197
TABLE OF CONTENTSp. 199
INSTRUCTIONS FOR CONTINUED AIRWORTHINESSp. 201
GENERALp. 201
EFFECTIVITYp. 202
SERIAL NUMBER EXPLANATIONp. 204
ASSIGNMENT OF SUBJECT MATERIALp. 204
PAGINATIONp. 204
AEROFICHE EFFECTIVITYp. 204
IDENTIFYING REVISED MATERIALp. 205
INDEXINGp. 205
WARNINGS, CAUTIONS, AND NOTESp. 205
ACCIDENT / INCIDENT REPORTINGp. 205
+SUPPLEMENTARY PUBLICATIONSp. 205
PIPER PUBLICATIONSp. 205
VENDOR PUBLICATIONSp. 206
SECTION INDEX GUIDEp. 3
