Ricoh MP 6002/7502/9002 (D131-D133) Service Manual PDF

Description

Ricoh MP 6002/7502/9002 (D131-D133) Service Manual PDF DOWNLOAD

Description

This is the D131/D132/D133 Service Manual for the MP 60–90 ppm series—designed for trained/certified technicians and workshop repair. It includes full machine configuration, installation steps for major accessories/options, PM checklists, removal/replacement procedures, SP mode guidance, firmware/service utilities, and deep troubleshooting (SC codes, jam diagnostics, timing charts).

✅ Models Covered (All Brands)

• D131: MP 6002 (also branded as **Lanier / Savin equivalents)

• D132: MP 7502

• D133: MP 9002

🗂️ Table of Contents (Neatly Categorized)

1) Product Information

• Specifications (see Appendices for general/peripheral specs)

• Machine configuration

  • Peripheral units + codes (LCT/LCIT, finishers, punch units, mailbox, folding unit, trays, jogger units, etc.)

  • Other options (interfaces, security, controller/SD options, fax options)

• Guidance for those familiar with predecessor products (differences, option name/code changes)

• Overview (mechanical layout, paper paths, drive layout)

2) Installation

• Installation requirements (environment, space, power, dimensions)

• Main machine installation (tapes/retainers, development unit handling, drum settings init, SP codes, heater connections, etc.)

• Options/peripherals installation (examples shown in TOC):

  • A3/11×17 tray, LCIT/LCT, multi-folding unit, finishers, punch units, jogger units, cover interposer, mailbox, copy tray, key counter/card reader brackets, connector options, MFP controller options (PS3, wireless, Bluetooth, encryption/DOS, VM card, etc.)

3) Preventive Maintenance

• PM tables: main machine (scanner optics, drum area, developer, paper feed, transfer belt, fusing/exit, duplex, ADF)

• PM tables: optional peripheral devices (LCT, interposer, finishers, punch, folding unit + related SP codes)

4) Replacement and Adjustment (Major Workshop Section)

• General cautions (drum, transfer belt, scanner, laser, fusing, paper feed, etc.)

• Special tools & lubricants

• Operation panel & covers

• Scanner (ADF, sensors, lamp, motor, wire replacement/position adjustment)

• Laser unit (LD/polygon motor, sync detector, alignment)

• Drum unit (corona, wires/grid, drum, blade/brush, filters, sensors, motors, toner collection, fans)

• Development unit (developer replacement, seals, TD sensor, supply motor, etc.)

• Transfer belt unit (belt, rollers, power pack, discharge plate)

• Fusing unit (thermistors/thermostats, web unit, lamps/rollers, nip band width, exit sensors/motors)

• Duplex unit (removal, adjustments, motors, sensors, belts)

• Paper feed (trays, fences/sensors, motors, rollers, registration, bypass unit/rollers)

• PCBs & HDD (controller/CNT, NVRAM, IPU, HDD, PSU/BCU boards, etc.)

• ADF (belts/rollers/sensors/motors/CIS, transport belt removal/reinstall)

• Copy image adjustments (print/scanning/ADF), touch panel calibration

5) System Maintenance (Service Mode / SP Mode)

• Resets (memory all clear, software/setting reset)

• Service Program (SP) mode: entry/exit + how to run test prints from copy window

• SMC printout, test pattern printing, firmware update, upload/download NVRAM data, I/O check, debug log use

6) Troubleshooting

• Service call conditions + SC code categories (SC100–SC900 groups)

• Important SP codes for diagnostics (free run, input/output check, SMC print, ROM/firmware version, self-diagnostic, last SC status)

• Jam detection (sensor locations, frequent jam diagnosis, jam codes, timing charts)

7) Energy Save / Paper Save

• Energy saver modes, timer settings, effectiveness of duplex/combine, etc.

🗂️ File Details

Stop guessing and fix it right the first time—this manual gives you the factory-level procedures, SP diagnostics, and repair steps you need. Instant download so you can start troubleshooting and servicing immediately.
