Komatsu PC200-8 PC200LC-8 PC220-8 PC220LC-8 Shop Manual SEN00084-07 PDF

Description

Komatsu PC200-8 PC200LC-8 PC220-8 PC220LC-8 Shop Manual SEN00084-07 PDF

The Komatsu PC200-8 PC200LC-8 PC220-8 PC220LC-8 Shop Manual SEN00084-07 PDF is a workshop-focused technical reference for four Komatsu hydraulic excavator models and their stated serial-number ranges. Across 1069 PDF pages, it brings together machine specifications, component construction and operating principles, maintenance standards, standard service values, test and adjustment procedures, troubleshooting, disassembly and assembly instructions, and hydraulic and electrical diagrams. It is designed around the information needed when diagnosing faults, checking machine performance, evaluating wear, removing components, carrying out repairs and returning systems to the specified condition.

Machine Coverage and Serial Number Applicability

This shop manual specifically identifies the following machines. Checking the model and serial number before using a procedure or value is important because the manual separates certain dimensions, performance figures, component arrangements and service data by model.

• PC200-8 – serial number 300001 and up
• PC200LC-8 – serial number 300001 and up
• PC220-8 – serial number 70001 and up
• PC220LC-8 – serial number 70001 and up

The specification section identifies the SAA6D107E-1 engine for these machines. The manual also distinguishes model-specific chassis and hydraulic details, including PC200/PC200LC and PC220/PC220LC dimensions, working ranges, operating weights, travel and swing data, undercarriage arrangements, hydraulic-cylinder sizes and selected component specifications.

File Details

• Manual type: Shop Manual
• Brand: Komatsu
• Models: PC200-8, PC200LC-8, PC220-8, PC220LC-8
• Document number: SEN00084-07
• Language: English
• Page count: 1069 pages
• File format: PDF

Specifications, Service Data and Machine Reference

The Komatsu PC200-8 PC200LC-8 PC220-8 PC220LC-8 shop manual begins with machine data that can be used before inspection or repair work starts. It includes specification dimension drawings, working-range diagrams, model-by-model specifications, a component weight table, and fuel, coolant and lubricant information. Examples of the data shown include overall dimensions, track dimensions, digging reach and depth, operating weight, bucket capacity, travel and swing performance, engine information, hydraulic pump details and cylinder dimensions.

The specification pages identify the SAA6D107E-1 as a 6-cylinder, 4-cycle, water-cooled in-line direct-injection engine with turbocharger and air-cooled aftercooler. The manual gives bore and stroke, displacement, rated output, maximum torque, idle speeds and electrical starting/charging details. Hydraulic information includes the HPV95+95 variable-displacement piston pump arrangement, control valve, travel and swing motors, hydraulic cylinders and tank/filter/cooler data. Fluid-capacity pages include engine oil, swing machinery, final drives, damper case, hydraulic system, fuel tank and cooling system figures for the applicable model groups.

Chapters Covered

• 00 – Index and foreword
  • Shop manual composition and table of contents
  • Safety notices and how to read the shop manual
  • Maintenance-standard terminology
  • Handling electrical equipment and hydraulic components
  • Engine connector handling and electric wire codes
  • Service-operation precautions and push-pull couplers
  • Standard tightening torque and conversion tables
• 01 – Specification
  • Specification dimension drawings
  • Working range diagram
  • Machine, engine and hydraulic specifications
  • Component weight tables
  • Fuel, coolant and lubricant information
• 10 – Structure, function and maintenance standard
  • Engine and cooling system
  • Power train, final drive, swing machinery and swing circle
  • Undercarriage and frame, including recoil spring, idler and rollers
  • Hydraulic system Parts 1, 2 and 3
  • Hydraulic tank, filter, pump, control valve and CLSS
  • Swing motor, travel motor, PPC valves, solenoid valves and hydraulic cylinders
  • Work equipment dimensions
  • Cab and air-conditioner piping
  • Engine control, electrical control, monitor, sensors and KOMTRAX terminal system
• 20 – Standard value table
  • Standard service values for engine-related parts
  • Standard service values for chassis-related parts

  IMAGES PREVIEW







• 30 – Testing and adjusting
  • Tools used for testing, adjusting and troubleshooting
  • Engine speed, boost pressure, exhaust gas, valve clearance and compression checks
  • Blow-by pressure, engine oil pressure and fuel-system testing
  • Swing-circle bearing clearance and track-shoe tension
  • Work-equipment, swing and travel hydraulic-pressure checks
  • Pump PC and LS control-circuit pressure adjustment
  • Solenoid and PPC valve output-pressure checks
  • Hydraulic drift, leakage, residual-pressure release and air bleeding
  • Machine monitor special functions
  • Electrical-system troubleshooting preparation, diode testing and Pm Clinic service
• 40 – Troubleshooting
  • Failure-code table and fuse locations
  • General troubleshooting procedures
  • Failure-code troubleshooting Parts 1 through 4
  • Electrical-system troubleshooting (E-mode)
  • Hydraulic and mechanical troubleshooting (H-mode)
  • Engine troubleshooting (S-mode)
• 50 – Disassembly and assembly
  • General procedures, coating materials and special tools
  • Engine and cooling-system component removal and installation
  • Final drive, swing motor, swing machinery and swing circle work
  • Undercarriage and frame disassembly and assembly
  • Hydraulic tank, control valve, pump, PPC valves and cylinders
  • Work equipment removal and installation
  • Operator cab, glass, front window and floor frame
  • Air conditioner, KOMTRAX modem, monitor and controllers
• 90 – Diagrams and drawings
  • Hydraulic circuit diagrams
  • Electrical circuit diagram
  • Connector arrangement diagram
  • Air-conditioner electrical circuit diagram

Taken together, these chapters make the Komatsu PC200-8 PC200LC-8 PC220-8 PC220LC-8 Shop Manual SEN00084-07 PDF much more than a basic maintenance guide. It connects system theory and component construction with measurable standard values, diagnostic procedures and hands-on repair instructions, allowing a technician to move from a symptom or fault code to checks, adjustments, component removal and reassembly using information from the same manual set.

Hydraulic and Mechanical System Depth

Hydraulic coverage is one of the strongest parts of this manual. The structure and function sections identify the hydraulic equipment layout and explain the tank and filter, HPV95+95 pump, PC and LS control, EPC valves, control valve, CLSS closed-center load-sensing system, pressure compensation, regeneration circuits, merge-divider operation, travel junction control, PPC circuits and drift-prevention functions. These explanations are supported by sectional drawings and circuit diagrams rather than just component names.

Mechanical service information extends through the final drives, swing machinery and swing circle, track frame, recoil spring, idler, carrier rollers, track rollers and track shoes. Maintenance-standard pages provide dimensional criteria, clearances and repair limits for many components, which is valuable when deciding whether a part remains serviceable or requires repair or replacement.

Testing, Adjustment and Troubleshooting

The testing and adjusting section provides procedures for checking machine condition with measured values instead of relying only on symptoms. It includes engine-related checks such as engine speed, boost pressure, exhaust color, valve clearance, compression pressure, blow-by pressure and oil pressure, together with fuel-pressure and return/leakage checks. Chassis and hydraulic procedures cover track tension, swing-circle clearance, work-equipment/swing/travel circuit pressure, control pressure, pump PC and LS control pressures, solenoid output, PPC output, hydraulic drift, leakage and air bleeding.

Troubleshooting is divided into fault-code diagnosis plus dedicated electrical, hydraulic/mechanical and engine modes. The failure-code material covers engine-controller, sensor, rail-pressure, injector, battery-voltage, CAN, pump-pressure, PPC-pressure and solenoid-related faults among many others. The E-mode section follows electrical symptoms such as no monitor display, no cranking, preheater problems, work equipment not moving, abnormal gauges, travel-speed issues, air-conditioner faults and KOMTRAX faults. H-mode addresses low work-equipment power or speed, pump noise, hydraulic drift, travel deviation, steering problems, swing problems and attachment-circuit behavior. S-mode covers engine starting, running, power, smoke, oil consumption, fuel consumption, overheating, abnormal noise and vibration.

Disassembly, Removal and Installation Procedures

For repair work, the manual includes step-by-step disassembly and assembly material with safety precautions, special-tool references, component weights, tightening torques and refill or air-bleeding instructions where applicable. Procedures cover fuel-system components, engine seals, cylinder head, cooling packages, engine/hydraulic-pump assembly, final drives, swing components, undercarriage assemblies, sprocket and tracks, hydraulic tank, main control valve, hydraulic pump, PPC valves, hydraulic cylinders, work equipment, cab components and electrical/control units.

The manual’s own structure notes that shop manuals are divided into chassis and engine volumes and directs the reader to the applicable engine volume for the engine unit. This PDF contains machine-side engine specifications, engine and cooling-system information, engine-related testing and troubleshooting, and selected engine-component removal/installation procedures, while the separate engine volume is referenced for engine-unit coverage.

Hydraulic and Electrical Diagrams

The closing diagram section provides dedicated hydraulic circuit diagrams for the PC200/PC200LC-8 and PC220/PC220LC-8 groups, together with an electrical circuit diagram, connector arrangement information and an air-conditioner electrical circuit. These drawings complement the earlier structure/function and troubleshooting chapters, making it easier to follow circuits, identify components and connectors, and relate test points or symptoms to the corresponding system.

Repair, Diagnose and Service with the Correct Reference

The Komatsu PC200-8 PC200LC-8 PC220-8 PC220LC-8 Shop Manual SEN00084-07 PDF supports detailed workshop tasks ranging from machine inspection and performance testing to hydraulic diagnosis, electrical fault tracing, component removal, disassembly, assembly and adjustment. Using the procedures, standard values, repair limits, tightening data and circuit drawings provided for these specific models helps keep repair decisions tied to the documented machine information rather than guesswork.

After purchase, the manual is delivered as an instant PDF download with no physical shipping required. It can be opened on compatible phones, tablets and computers, stored for workshop reference, and printed when a paper copy of selected procedures or diagrams is useful.
