Mitsui-Paceco Portainer Crane Electrical Parts Volume 3-3 Operation and Maintenance Manual – BT4376
Original price was: $44.95.$27.95Current price is: $27.95.
Electrical parts operation and maintenance manual for the Mitsui-Paceco Portainer six-crane fleet at Haiphong International Container Terminal (MES Job BT4376, Serial 4616~4621). Covers Smart Transmitters, Smart Cam converters, speed relays, loadcell converters, wind speed meters, SIRRAH anti-sway, BMU beacons, intercom and warning systems, Crane Monitoring System software, Smart-UPS, AXIS IP cameras, truck positioning and LF70E flood lights. English, 482-page PDF.
Description
Mitsui-Paceco Portainer Crane Electrical Parts Volume 3-3 Operation and Maintenance Manual – BT4376
This Mitsui-Paceco Portainer Crane Electrical Parts Volume 3-3 Operation and Maintenance Manual is the electrical systems service reference for the six Portainer cranes delivered to Haiphong International Container Terminal Company Limited. Issued under MES Job No. BT4376 with MES Serial Nos. 4616~4621 and MES Spec. No. TBD180857 in October 2018, this is the third and final volume of the electrical parts instruction set. It covers the advanced sensor, anti-sway, warning and intercom, monitoring, camera, truck positioning and flood light systems installed on these ship-to-shore cranes. Every page is aimed at the maintenance electrician, commissioning engineer and service technician responsible for keeping this Portainer fleet operational in a busy container terminal.
File Details
- Manual Type: Operation and Maintenance Instruction Manual – Electrical Parts (Volume 3-3)
- Brand / Manufacturer: Mitsui-Paceco (Mitsui E&S Machinery Co., Ltd.)
- Equipment: Portainer Six (6) Cranes
- Customer: Haiphong International Container Terminal Company Limited
- MES Job No.: BT4376
- MES Serial Nos.: 4616~4621
- MES Spec. No.: TBD180857
- Date: October 2018
- Language: English
- Page Count: 482
- File Format: PDF
Chapters Covered
- G SENSOR
- G-1 Smart Transmitter (TA4755N□□4) – Hoist, Trolley, Boom Position
- G-2 Smart Cam (TA4570N500E110) – Hoist, Trolley, Boom Position
- G-3 Speed Relay (ESRU-100/ESRB-100) – Hoist, Boom Over Speed
- G-4 LC1111 Loadcell Converter
- G-5 Wind Speed Meter with Alarm (TM-010E / NB320)
- H ANTI-SWAY SYSTEM
- H-1 User’s Manual SIRRAH TS 19
- H-2 User’s Manual for Beacon BMU
- I WARNING SYSTEM & INTERCOM
- I-1 Amplifier for Speaker (CA-600DN)
- I-2 Selective Call Intercom (TD-12H/B)
- J MONITORING SYSTEM
- J-1 Crane Monitoring System (CMS)
- J-2 Smart-UPS Operation Manual
- K CAMERA SYSTEM
- K-1.1 Camera (AXIS P3225-VE Mk II)
- K-1.2 Camera (AXIS Q1765-LE)
- K-2 Camera Monitor System Application Operating Instructions
- L TRUCK POSITIONING SYSTEM
- L-1 Specifications – Truck Positioning System (TPS)
- M OTHER
- M-1 Flood Light (LF70E)
What This Electrical Volume Covers
The Mitsui-Paceco Portainer Crane Electrical Parts Volume 3-3 Operation and Maintenance Manual picks up where the first two electrical volumes leave off. It is dedicated to the intelligent subsystems that make these Portainer cranes safer, more precise and easier to monitor. The volume opens with the sensor group: the Tamagawa Smart Transmitter and its Smartsyn resolver stack for hoist, trolley and boom position feedback, the Smart Cam converter that turns position data into programmable cam outputs, the Matsushima speed relay used for hoist and boom over-speed protection, the Unipulse LC1111 loadcell converter, and the NB320 wind speed meter with two-point alarm. Together these components form the position, load and safety sensing layer of the crane.
The anti-sway section documents the SIRRAH TS19 optical angle sensor and the BMU universal beacon that work together to control sway and skew on the container crane. The warning and intercom section covers the TOA CA-600DN car amplifier for speaker announcements and the Aiphone TD-12H/B selective call intercom system with its multi-channel station-select network, door station and paging capabilities. The monitoring system section explains the Crane Monitoring System (CMS) – a Windows-based package with fault records, trace-back, operation data, maintenance management, reporting and remote CMS features – plus the APC Smart-UPS uninterruptible power supplies that protect the control system.
The camera system section covers the AXIS P3225-VE Mk II fixed dome camera, the AXIS Q1765-LE PT mount camera, and the custom Camera Monitor System application that displays six IP camera feeds split across the operator’s cab monitor. The truck positioning system section provides the full TPS specification, describing the 2D laser sensors mounted on the portal tie beam, the LED displays that guide truck drivers to the correct loading position, and the PLC-based control and interlock logic. The final section covers the LF70E flood light, including its connection options, mounting configurations, module replacement and maintenance guidance.
Systems and Components Documented
Across its 482 pages the manual presents each subsystem with the detail a field technician needs: scope, mechanical outline and dimensions, internal structure, wiring and connection diagrams, cable specifications, terminal assignments, DIP-switch and jumper settings, calibration and adjustment procedures, parameter programming via the dedicated hand-held terminal, troubleshooting tables, alarm codes, maintenance procedures and warranty terms. The Smart Transmitter section includes type numbering, mounting accuracy limits, cable end options and extension cable references. The Smart Cam section provides the full parameter menu structure, cam programming and teaching flow, PIO and SIO output assignment tables, timing charts and error code list. The speed relay section gives construction views, adjustment methods, wiring details and replacement parts. The SIRRAH and BMU beacon sections include installation geometry, wiring for RS-232, RS-422 and Profibus links, operating mode descriptions and status LED interpretation. The CMS and UPS sections document software operation and backup power configuration.
IMAGES PREVIEW
Additional sections give detailed specifications for the Smart Transmitter TA4751, TA4755, TA4757, TA4765 and TA4767 series, including type numbering for size, water resistance, full scale revolutions, cable length and mounting connection. The Smartcam section includes the multi-turn full absolute detection table for the N4 through N9 gear ratios, the combination list for the TA4561 handy terminal and TA4562 I/O terminal, and the PIO output signal assignment for the cam-plus-position modes. The SIRRAH section documents sensor characteristics, physical dimensions, beacon orientation, Profibus termination resistor values and the LED status indicator table. The TPS section includes the system configuration, operation flow, interlock and alarm list, and the check list dimensions used to set up truck lanes and trailer positions.
Who This Manual Is For
This is the manual for the electrical maintenance team, the commissioning engineer and the terminal’s technical support staff. It supports daily fault-finding on the crane’s intelligent sensing systems, correct parameter set-up after component replacement, calibration of anti-sway and position feedback, camera network configuration, truck positioning system checks and the safe handling of the UPS and flood light equipment. It also gives managers and engineers the documentation needed to understand how the crane’s electronic subsystems are put together and how they should be maintained.
Why This Manual Matters
On a Portainer crane, an out-of-adjustment resolver, a mis-set cam, a failed speed relay or an uncalibrated anti-sway sensor can stop a vessel operation and risk cargo or personnel. Having the correct wiring diagram, parameter list, alarm code explanation and adjustment value close at hand is the difference between a quick fix and hours of guesswork. This Mitsui-Paceco Portainer Crane Electrical Parts Volume 3-3 Operation and Maintenance Manual delivers exactly that – the manufacturer’s own documentation for the exact crane serial numbers in service.
Delivery
The manual is delivered as an instant-download PDF after payment. No shipping, no waiting. Open it on a laptop, tablet or phone in the workshop or the cab, print the pages you need for the job, and keep the full document for future reference. The PDF stays on your device – no subscription, no time limit.
Equip your workshop with the Mitsui-Paceco Portainer Crane Electrical Parts Volume 3-3 Operation and Maintenance Manual – BT4376 and get every sensor, converter, intercom, camera and anti-sway component covered by the manufacturer’s own electrical documentation for the Haiphong International Container Terminal Portainer fleet.
