STILL RX20 Electric Forklift Spare Parts Catalogue 6219-6231 – RX20-14C to RX20-20PL Parts List PDF

Description

STILL RX20 Electric Forklift Spare Parts Catalogue – Truck Codes 6219 to 6231

This is the full STILL spare parts list for the RX20 electric counterbalance truck family, published under catalogue reference 6219-6231. Every assembly on the machine is broken down into exploded illustrations with numbered callouts, followed by the matching part number, quantity and description rows, so a part can be identified on the drawing and ordered from the same page. The catalogue spans the whole RX20 range – RX20-14C, RX20-16C, RX20-16, RX20-16L, RX20-18, RX20-18L, RX20-20L and the RX20-16P, RX20-16PL, RX20-18P, RX20-18PL, RX20-20P and RX20-20PL derivatives – and is organised the way a workshop actually works: by functional group, from the traction motor out to the fork tips.

File Details

• Manual type: Spare parts list / parts catalogue (Ersatzteilliste)
• Brand: STILL
• Machine type: Electric forklift truck (counterbalance)
• Series: RX20 14-20
• Catalogue reference: 6219-6231
• Language: English part descriptions, remarks and column headings, with multilingual front matter (German, English, French, Italian, Spanish)
• Page count: 3,193
• File format: PDF
• Page footers in this copy: stamped 02.06.2026 / 2020.06.2026

Because this is a genuine factory parts breakdown rather than a generic overview, the level of detail is unusually deep: sub-assemblies are split down to individual bearings, O-rings, lock rings, seals, screws and washers, and each line carries its own quantity and any date or model validity note that applies.

Chapters Covered

• Product Information
• Service
• Electric Motor
• Mechanical Drive
• Axle
• Chassis
• Operator’s Compartment
• Steering System
• Wheels and Tyres
• Braking System
• Controls
• Display Element
• Electrics; Electronics
• Electronic Controls
• Hydraulic
• Working Hydraulics
• Valves
• Load Lifting System
• Mast
• Load Support
• Attachments
• Special Equipment
• Narrow Aisle Trucks
• Other Accessories

Electric Motor and Mechanical Drive

The traction motor section separates the left-hand and right-hand motor assemblies and lists rotors, bearing flanges, grooved ball bearings, locking rings, threaded pins, seals, cable inlets, grommets and socket head screws individually. The lift/pump motor is listed with its bearing shield, shaft seal, rotor, bearing cover, temperature sensor, rubber mountings and the associated cable part numbers. The drive unit chapter covers the propshaft, converter assemblies (with a split at 09.10.2020), the air ducting, fan variants, supports, clamps and the wiring harness assemblies that feed the drive.

Drive Axle, Wheel Gear and Multi-Disc Brake

A full drive-axle exploded view is followed by the wheel gear breakdown – shaft seal, slotted nut, screw plugs, O-rings – and the multi-disc brake assembly with thrust piece, discs, compression springs, brake lever, spherical bearing and snap ring. Radial seal rings, bellows, bleeder valves, rev sensors and temperature sensors are all itemised, which makes this section the one to open for a weeping hub seal or a dragging brake.

Chassis, Counterweight and Tow Coupling

Chassis assemblies are listed in short, standard and long versions, plus skirting-board variants, with collision protection, bottom plates, floor mats, sealing profiles, quick-release clamps, pedals and floor plate harnesses. The counterweight chapter covers each truck code separately (6219 through 6231), including raised driver’s seat versions, coupling pins, thrust pieces, bolts, mudflaps and spring covers, followed by tow coupling, stop, holding fixture and blank counterweight plates.

Operator’s Compartment, Cab and Seat

Side panels are catalogued with retainer plates, sheet metal holders, bearing bushes, catch bolts, locks, handles, rods, spring elements, shock mounts and corrosion-protected variants. The cab section covers wiper units and blades, windscreens, rear windows, washer systems with pumps and non-return valves, roof panels, rain gutters, sunblinds, interior and exterior mirrors, doors with gas springs and door windows, canvas covers, headliners, speakers and radios. Driver’s seats are broken down as MSG 65 and MSG 75 units plus a full single-parts list – cushions, upholstery, backrests, head restraints, seat contact switches, belts, buckles, rails, handles and covers.

Steering System

Hydraulic steering is split into steering turntable and swing axle configurations, with steering control valves, priority valve and seal kit, hose lines with O-rings and unions, gear pump, tappet and the steering column assembly with steering wheel, sensor, gear segment, flange bearings and stops. The steering axle itself is fully exploded – axle beam, axle casing, wheel hubs, tapered roller bearings, track rod, cylinder assembly, steering arm, rack rail, pistons and grooved rings.

Wheels, Tyres and Braking System

Tyre pages are grouped by size and track width – 180/70-8, 200/50-10, 125/75-8, 140/55-9 and 150/75-8 – with solid tyre, super elastic tyre, disc wheel, complete wheel assembly and wheel screw or nut part numbers, including Conti and Trelleborg options in black, natural and antistatic. The braking chapter covers the service brake with potentiometer, pedal cover, tension springs and shims, and the parking brake in both mechanical handbrake form and electrical form with toggle switch, cable pulls and cable routing by driver’s seat height.

Controls, Display and Switches

Two-pedal drive actuation is shown as a complete assembly with accelerator and brake pedals, pedal covers, needle bearings, compression springs, gears, pinion gear, potentiometer and locking varnish. Multi-lever actuation levers (1st to 4th lever, with and without switch), mini-lever and joystick operating units, fingertip II consoles, armrests and the full control symbol/label range are catalogued, along with key switches, emergency off switch, push button start/stop and the adapter cable kit.

Electrics, Electronics and Sensors

This is one of the largest chapters in the catalogue: roof and chassis control cable looms for multi-lever and proportional trucks, steering column harnesses for standard, mini-console, CPP2, TDU and warning light switch combinations, voltage transformer primary and secondary harnesses, lighting and working spotlight harnesses, extension cable sets, earth cables, fuse boxes, voltage converters, option board, PDU, CPP 1 to CPP 5 control units and CAN distributors. Sensor pages list tilt angle, crash/acceleration, ceiling, battery door, cabin door, steering, temperature, pressure and lift height sensors with their brackets and hardware.

Hydraulics and Valves

Basic hydraulics covers suction filter, gear pump, return flow filter with breather filter, priority valve, temperature sensor, lift and tilt hose lines and the high-pressure filter with insert and seal set. Directional control valve blocks are listed as 2-way, 3-way and 4-way multi-lever assemblies with levers, joining plates, bolts, spring pins and axles, and separately as proportional control blocks with solenoid valves, throttle valves, pressure relief valve, valve cartridges, non-return valves and brake valves.

Load Lifting System, Masts and Attachments

Mast coverage is divided into Mono, Tele, NiHo and Triplex, each with common parts (rollers, tensioners, chain rollers, guides, hose pulleys, energy chains, leaf chains in many lengths), lift cylinders by piston diameter for 1.4 t to 2.0 t duties, and the tilt cylinder range with 410 mm, 417 mm, 425 mm and 431 mm variants. Load support chapters give fork carriage and integrated sideshift assemblies in 4-roller and 6-roller form, plus fork arms in ISO class 2 in 80×35, 80×40, 100×40 and 100×50 sections across a wide range of lengths, fork extensions, screen grids, sideshifts, forkshifts, bale clamps, clamp forks, rotators, mandrels, crane jibs, telescopic forks and buckets.

Batteries, Chargers and Special Equipment

Battery side coverage includes appliance plug assemblies for Schaltbau LV160, LV320, LV320 Li-Ion, SRE 320 blue and DIN 320A Rema, battery harnesses for each connector type, lithium-ion battery assemblies BG 2.1 to BG 9.3 with modules, conductor rails, slave cards, temperature sensors, brake resistors, charging devices at 9 kW and 18 kW, on-board chargers, battery carriers with reach cylinders and rollers, water tanks, antiskid coverings and service labels. Special equipment pages add wheel chock, reservoir, water drain, fire extinguisher, reflectors and warning signs, along with plates, identification plates, speed labels, load capacity plates and inspection stickers.

Why This STILL RX20 Parts Catalogue Belongs in the Workshop

Guessing a part number on a 1.4 to 2.0 tonne electric truck is an expensive habit. A wrong bearing, a seal that does not match the housing, a brake disc fitted to the wrong side of a serial break – each one costs a second strip-down, a second order and a second window of downtime. This catalogue removes the guesswork because the number on the drawing and the number in the parts row sit on the same spread, and the remark column carries the date splits and model validity that catch most ordering errors before they happen.

It supports real jobs: rebuilding a traction motor, replacing a wheel gear shaft seal, chasing a brake that will not release, renewing mast rollers and chains, matching a lift cylinder to the right piston diameter, identifying which roof loom fits a proportional truck with a heater and an electric parking brake, or ordering the correct plug assembly for a Li-Ion battery. Diagnostics benefit too, because sensor and harness pages let you trace a fault from the sensor through the connector to the control unit rather than replacing parts on suspicion.
