Volvo EC250D Excavator Parts Catalog 20035940-B February 2015 PDF

Description

Volvo EC250D Excavator Parts Catalog 20035940-B

This is the complete illustrated parts catalog for the Volvo EC250D excavator, published under reference number 20035940-B in February 2015. It serves as the definitive reference for identifying, locating, and ordering genuine components for machines within the specified serial number ranges. The catalog is structured to help technicians, parts managers, and owners quickly find the exact part numbers needed for maintenance, repair, and rebuild projects.

File Details

• Manual Type: Illustrated Parts Catalog
• Brand: Volvo Construction Equipment
• Model: EC250D Excavator
• Publication Number: PUB 20035940-B
• Edition/Date: February 2015
• Language: English, Spanish, Portuguese, French (Multilingual)
• File Format: PDF
• Coverage: S/N 210001-, 220001-, 230001-, 240001-, 260001-, 270001-, 280001-

Chapters Covered

The catalog is organized into ten major groups, each addressing a specific system or assembly of the machine. Each group contains detailed illustrations and corresponding part number tables, allowing for precise identification of every component.

• Group 1: Preface and Instructions — Title page, publication number, group index, product signs, preface, equipment variants, catalog guide, and abbreviation table.
• Group 2: Engine — Engine assembly, cylinder head, cylinder block, cylinder liner and piston, valve mechanism, timing gear casing, crankshaft, flywheel housing, oil sump, lubricating oil system, fuel system, cooling system, turbocharger, inlet and exhaust manifolds, and engine management systems.
• Group 3: Electrical Systems and Instruments — Key system, battery, alternator, starter motor, pre-heater, lighting, interior lamps, windscreen wipers, switches, electronic units, cables, instrument panel, warning units, rear-view camera, radio, and telematics systems.
• Group 4: Power Transmission — Travel gearbox, swing gearbox, pump gearbox, travel motor, swing motor, turning joint, swing system, and swing gear covers.
• Group 5: Hydraulic Systems — Hydraulic oil tank, control valve to boom and swing, turning joint lines, hydraulic tank to oil cooler, hydraulic tank to pump, oil cooling system, main control valve, working hydraulics for boom, dipper arm, bucket, hammer, shear, quick fit, and rotator systems, servo systems, and attachment brackets.
• Group 6: Frame and Crawler Unit — Protecting plates, counterweights, foot steps, track chains, track guards, spring packages, front idler, top rollers, bottom rollers, and sprockets.
• Group 7: Body with Associated Parts — Cab body, framework, roof, operator’s cab, cab mounts, cowl frame, engine hood, side doors, roof hatches, cabin floor, rear-view mirrors, glass panes, operator seats, seatbelts, covers, sun visors, falling object guards, air conditioning lines, air ducts, auxiliary heater, interior components, instrument panels, anti-slip surfaces, tools, and decals.
• Group 8: Miscellaneous Equipment — Vandalism kit, fire extinguisher, automatic lubrication systems, air compressor, and associated components.
• Group 9: Numerical Index — A complete numerical index of all part numbers referenced in the catalog, with cross-references to group, section, and page numbers.

What This Parts Catalog Provides

This document is not a repair manual; it is a comprehensive parts identification and ordering tool. It provides exploded-view illustrations for every major assembly, with each component clearly numbered and cross-referenced to a detailed table containing the part number, description, and quantity required. This structure allows anyone to visually identify a part, confirm its exact part number, and order the correct replacement without guesswork. Whether you are rebuilding a hydraulic cylinder, replacing undercarriage components, or sourcing cab interior parts, this catalog ensures you are working with the correct Volvo part numbers for your specific EC250D serial number range. The inclusion of multiple language columns (English, Spanish, Portuguese, French) makes it accessible to a wide range of users.

Why This Catalog Is Essential

Using the wrong part number can lead to costly delays, improper fitment, and potential damage to surrounding components. This catalog eliminates that risk by providing the exact part numbers that correspond to the specific serial number breaks of the EC250D. It is the same reference used by Volvo parts professionals, ensuring that every order is accurate. For fleet managers, independent repair shops, and owner-operators, having this catalog on hand means faster diagnostics of parts needs, reduced downtime, and confidence that the correct component is being installed.

IMAGES PREVIEW

Instant PDF Delivery

This Volvo EC250D Excavator Parts Catalog is delivered as a high-quality PDF file, available for immediate download after purchase. There is no shipping, no waiting for a physical book, and no risk of lost mail. You can access it on any device—laptop, tablet, or smartphone—and print the pages you need for use in the workshop. The PDF format allows for easy navigation and the ability to zoom in on detailed illustrations for precise part identification.
